Digital fire detection control panel
COMPACT LYON
FIRE PRETECTION MANUFACTURER 7
Ctra. de Molins de Rei a Rubí, Km. 8,4 - 08191 RUBÍ (Barcelona) ESPAÑA.
Tlf.: +34 935 862 690 - Fax:+34 936 999 261 - cofem@cofem.com - www.cofem.com
Display
CPU
Switching Power Supply
Power suppl
Figure 1. Layout of circuits in the control panel
1.5. - External Components
The above table contents the information required about limits and equivalences of the references to
determine the maximum number of devices to be connected by loop and Control panel.
EXAMPLE: It is wanted to connect 15 MDA1Y and 50 A30XHA. The 15 MDA1Y equivalence is 75
elements, and 50 A30XHA is 50. Total of 125 elements. It can not be installed as it is overcomed the limit of
99 elements per loop.
In the same way, it must be checked the maximum number of devices, the logic relays and the loop
isolators, including total number of them by Control Panel. This task can be performed using EASYcoNET
software.
Note: the limits of the system can be above of the limits shown in the previous table. It can be made
consults to Technical Service to know the system limit of a specific configuration.
Devices limit per Control Panel
Reference Description
Loo
p
limi
t
Control
Panel
Limit
Element
equivalence
Logical
Relays
Equivalence
with loop
Isolator
A30XHA
Analogue optical-thermal sensor
99 198 1 --- ---
A30XHAS
Analogue optical sensor
99 198 1 --- ---
A30XTA
Analogue thermal sensor
99 198 1 --- ---
A30XHTCO
Optical-thermal-CO multi-sensor
99 198 1 --- ---
PUCAY
Analogue Manual Call Point
70 140 1 --- 1
KMAY
Conventional zone master module
19 38 5 --- 1
MDA2Y
Relays module
16 32 5 2 1
MDA1Y
Relay module
19 38 5 1 1
MYOA
Relay and Technical Signal module
19 38 5 1 1
MSTAY
Technical signal module
49 98 2 --- 1
KABY
Loop isolator
70 140 --- --- 1
SIRAY/ SIRAYL
Analogue sounder
6 12 10 1 1
Control Panel Limits:
a) 99 elements, 32 logic relays and 70 isolators per loop.
b) 2 loops, 64 logic relays per Control panel.
