Cognex Checker 3G Series User Manual

4
5
COGNEX
24 VDC+ −
Checker 3G Products and Accessories
Checker 3G Series Systems
3G1
Part Detection √
Trigger Input Line √
Discrete Outputs 2
Personalities 2
Presence √
Measurement √
Flying Lead Cable (C3G-CBL-001)
Connects Checker directly to your equipment (5m).
Mounting Bracket (CKR-200-BKT)
Provides exible mounting options for Checker.
SensorView Teach Pendant (SV-350-001)
Standalone control panel that lets you congure, manage,
and monitor a Checker 3G sensor.
Lens Kit (CKR-200-LENSKIT)
Set of 3.6mm, 8mm, 16mm, and 25mm lenses that provide
expanded eld of view and working distance options.
M12 USB Cable (CKR-200-CBL-USB)
Provides an IP67-compliant USB connection from Checker to
the PC (5m).
I/O Extender (CKR-200-CBL-EXT)
Power and I/O extension cable (5m).
Right-Angle Cable (CKR-200-CBL-RT-003)
Power and I/O extension cable with low-prole right-angle
connector for Checker sensor (1m).
