Cognex Checker 3G Series User Manual

6
7
67 (2.64)
22 (0.87)
39 (1.54)
60 (2.36)
41 (1.61)
mm (in)
27.5+0.5
(1.08+0.02)
67 (2.64)
22 (0.87)
39 (1.54)
60 (2.36)
41 (1.61)
mm (in)
27.5+0.5
(1.08+0.02)
1
2
3
4
6
7
5
2
8
1
Dimensions and Features
1 Mounting holes (M4 x 4 mm)
2 Focus lock (M3, use 2.5 mm hex key)
3 Lens cover/focus ring
4 Status LED (GREEN):
On: Run mode•
Slow blink: Setup Mode•
Fast blink: Internal error•
5 Part detect LED (RED)
6 USB connector with M12 plug
7 USB connector cover (cover or IP67 USB cable must be used for IP67 protection)
8 Power and I/O connector with M12 plug
