23
SECTION 6: PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY. NOTES
1 408502 Stacker/Encoder Housing & Board Assy. 1
2 408054 Upper Transport Pulley & Hub Assy. 2
3 407254-5 Transport Motor Gearbox Assy 1 Includes #4
4 920000-3 Encoder Wheel 1
5 408526 Stacker Pushplate Assy. BillPro 1 Includes #6 & #7
6 920836 Stacker Cap 4
7 920833-1 Stacker Slide 4
8 925202 Belt Tension Spring 1
9 407253-8 Stacker Motor Gearbox Assy. 1
10 920829-1 Idler Pulley 2
11 408055 Lower Transport Pulley& Hub Assy. 2
12 921403 Chassis Belt 2 Black
13 408527 Chassis With Connectors 1 Includes 925234 with connectors
925234 Upper Housing Chassis 1 Without connectors
14 925236 Upper Sensor Cover 1
15 345-4R4 Screw 2 #4 X 1/4 PH plastite
16 408501 Upper Sensor Board 1
17 925507 Maghead gasket 1
18 920893-2 Sensor Mount 1
19 925235 Upper Sensor Enclosure 1
20 920040 Wheel Shaft 3
21 408057 Inlet Pulley & Hub Assy. 2
22 407500 Harness 1 not shown
23 901358 4" Cable Tie 1 not shown
