Coinco BillPro - Component Explanation Drawing

8
SECTION 3: OPERATION
Figure 3
Component Explanation
Bill Box Lid
Intermediate Frame
Flex Stack
Bill Box
Lower
Housing
Center Drive
Belt
Left
Alignment
Sensor
Chassis Belt
Anti-Pullback
Lever
Pusher
Plate
Stacker Home
Encoder Sensor
Right
Alignment Sensor
Pushplate
Assy
Center Optic
Left-Right
Optic
Rollers
