compacta_g - 02_05
4.4.2 Description and use of heating/mixing side
The heating side is on top of the machine and consists of a heating/mixing cylinder, the
chamber where the mix is heated, in which a beater for stirring the product is placed.
The heating cylinder is hermetically closed by front lid 301 which can be opened by lifting and
pulling the lever 289 towards the right.
In this side, the machine can heat (mix or boil) while beating up to a temperature that can be
set 50° C to 85°C.
CAUTION !
Milk ice cream mixes need to be mixed at 65°C, at least.
Mixing at a lower temperature only suits fruit ice cream mixes.
From STOP position being activated, the mix poured into the boiling cylinder is heated by
pressing the key .
The top display will show the temperature of the product inside the cylinder.
To display set value of heating temperature, press .
In order to pour the mix into the cylinder, lift ice cream door 290.
301
290
5
289
290
