Coleman Powersports RTK196 - Front Wheel Assembly; Hardware for Front Wheel; Front Wheel Installation Steps; Hub Cap Installation

4
Hardware:
FRONT WHEEL ASSEMBLY
1
2
M14Washer 2ea. (1) 4
M14 Castle nuts 2ea. (2)
3
Cotter pins 2ea. (3)
Gasket 14 2ea. (4）
1.Lift the Kart with a
jack.
2.Install the front wheel with
gasket14(4),M14Washer(1),
M14Castle nuts and Cotter
pin.
Note:Make sure the Gasket install
direction is correct.
Tread
faces
forward
3、Install Hub Caps (5)
by snapping on hub.
2
!
W ARNING
Failing t o install co tt er pins
could be hazardous.
Failing t o install co tt er pins
could cause the castle nuts
t o fall off resulting in an
accident.
Nev er operat e Go Kar t
without co tt er pins installed .
4
1
2
3
5
