Parts List
2
1
5
3
4
6
Accessories (sold separately
and supplied with some models)
No. Part Number Description
8 & 9 2000000504 Griddle w/Cup*
10 5444-1171 Griddle Cover
11 2000000505 Carry Case
12 R5470-564A Hose Assembly
No. Part Number Description
8 5444-3151 Griddle
9 5444A1201 Grease Cup
*You may purchase the Griddle or
Grease Cup individually as follows:
No. Part Number Description
1 5444-5401 Pot Support
2 5444-3251 Burner Assembly 2-Hole (1 pk)
5010000171 Burner Assembly 4-Hole (1 pk)
3 5444-3261 Burner Assembly (1 pk)
4 5430-5651 Regulator Assembly
5 5444-1501 Large Control Knob (1 pk)
6 5444-1451 Small Control Knob (1 pk)
7 9922-4051 Foot w/ screw (1 pk)
7
8
9
11
10
Storing the Griddle
n Place the grease cup under the pot support.
n To protect the non-stick surface, place the
griddle into the griddle cover.
n Invert the griddle and place on the pot support.
n Close the wind baffles and the stove lid.
n Make sure stove and griddle are cool.
n Wipe clean with soft cloth and mild dish
detergent. Do not use abrasive on the
non-stick griddle surface.
Cleaning the Griddle
9
12
Things You Should Know
1. It is unsafe and illegal in some places to store
or use LPG bottles indoors. Never store gas
bottles in living spaces.
2. If using refillable LPG bottle, use only Coleman
parts and accessories.
3. The usual storage areas for camping and picnic
equipment are the basement, attic, or garage.
To avoid the accumulation of dust, cobwebs,
etc., that is common in these areas, place your
stove in a plastic bag and seal it with a rubber
band.
4. For repair or service call the number on the
front cover for location of your nearest Coleman
Service Centre.
