5547666-CTG-A-0718
Johnson Controls Unitary Products 11
— = Not applicable.
CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
CH16B4821S MVC20DN21 24.5 CF/CM64D
High 1550 48.0 37.2 17.00 10.25 46.5 29.8 10.00 8.00 3.50 2.82
Med 1025 33.6 25.8 – 15.95 – – – – – –
Low 1025 27.6 23.4 – 28.50 20.8 – – – 4.30 –
CH16B6021S AE60DBG21 24.5 –
High 1850 56.0 39.0 16.00 9.90 59.0 33.2 9.10 7.95 3.34 2.60
Med 1175 38.0 27.0 – 14.85 – – – – – –
Low 1150 31.2 23.8 – 25.50 25.6 – – – 4.14 –
CH16B6021S AE60DX21 24.5 –
High 1850 56.0 39.0 16.00 9.90 59.0 33.2 9.10 7.95 3.34 2.60
Med 1175 38.0 27.0 – 14.85 – – – – – –
Low 1150 31.2 23.8 – 25.50 25.6 – – – 4.14 –
CH16B6021S AVC60DX21 24.5 –
High 1400 55.5 39.0 16.25 10.00 58.5 32.0 9.25 7.60 3.40 2.74
Med 1075 36.6 27.8 – 15.00 – – – – – –
Low 1075 31.2 25.4 – 27.35 25.4 – – – 4.28 –
CH16B6021S MVC20DN21 24.5 CF/CM64D
High 1775 57.5 44.0 16.25 10.25 58.5 32.6 9.50 7.80 3.60 2.74
Med 1125 37.8 29.2 – 15.25 – – – – – –
Low 1125 31.2 26.4 – 27.10 25.2 – – – 4.28 –
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
1. Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in watt-hours during the same period.
2. Heating MBH based on AHRI standards of 70°F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping and no supplemental electric heat operation.
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input during the same period.
COP (Coefficient of Performance) equals Heating MBH output divided by (total KW input x 3.412).
SYSTEM CAPACITY - Single Piece and Modular Air Handlers (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
Stage
RATED
CFM
COOLING
1
HEATING
2
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
CH16B2421S TM8V060A12MP12C 14.5 CF/CM24A
High 800 24.0 18.6 17.25 11.75 24.0 15.0 9.00 7.50 3.56 2.60
Med 575 18.2 14.2 – 16.60 ––––––
Low 575 16.1 13.3 – 28.55 12.0 – – – 3.96 –
CH16B2421S
TM8V060A12MP12C 14.5 CF/CM30A
High 650 24.0 17.4 16.75 11.75 24.0 14.8 8.75 7.30 3.40 2.56
Med 450 17.4 12.5 – 15.90 – – – – – –
Low 450 15.7 11.7 – 27.55 11.7 – – – 3.74 –
CH16B2421S TM8V060A12MP12C 14.5 CF/CM36A
High 925 24.6 19.3 18.00 12.00 24.6 15.0 9.00 7.40 3.64 2.66
Med 650 18.5 15.3 – 17.15 ––––––
Low 650 16.4 14.5 – 30.35 12.3 – – – 4.24 –
