5547666-CTG-A-0718
12 Johnson Controls Unitary Products
CH16B2421S TM8V060A12MP12C 14.5 CF24ABAA1
High 800 24.0 18.6 17.25 11.75 24.0 15.0 9.00 7.50 3.56 2.60
Med 575 18.2 14.2 – 16.60 – – – – – –
Low 575 16.1 13.3 – 28.55 12.0 – – – 3.96 –
CH16B2421S TM8V060A12MP12C 14.5 CF30ABAA1
High 650 24.0 17.4 16.75 11.75 24.0 14.8 8.75 7.30 3.40 2.56
Med 450 17.4 12.5 – 15.90 ––––––
Low 450 15.7 11.7 – 27.55 11.7 – – – 3.74 –
CH16B2421S TM8V080B12MP12C 17.5 CF/CM24B
High 875 24.0 19.5 17.75 12.00 24.0 15.1 9.00 7.40 3.72 2.66
Med 625 18.4 15.0 – 16.85 – – – – – –
Low 625 16.4 14.2 – 29.40 12.3 – – – 4.16 –
CH16B2421S TM8V080B12MP12C 17.5 CF/CM30B
High 775 24.0 18.4 17.75 12.00 24.0 15.0 9.00 7.45 3.64 2.66
Med 625 18.5 15.1 – 16.90 ––––––
Low 625 16.4 14.2 – 29.45 12.3 – – – 4.14 –
CH16B2421S TM8V080B12MP12C 17.5 CF/CM36B
High 800 24.0 18.7 17.75 12.00 24.0 15.0 9.00 7.45 3.66 2.66
Me 625 18.5 15.0 – 16.90 – – – – – –
Low 625 16.4 14.2 – 29.55 12.3 – – – 4.16 –
CH16B2421S TM8V080B12MP12C 17.5 CF24BBAA1
High 875 24.0 19.5 17.75 12.00 24.0 15.1 9.00 7.40 3.72 2.66
Med 625 18.4 15.0 – 16.85 ––––––
Low 625 16.4 14.2 – 29.40 12.3 – – – 4.16 –
CH16B2421S TM8V080C16MP12C 21.0 CF/CM24C
High 900 24.0 18.6 17.50 11.75 24.0 15.1 9.00 7.45 3.56 2.62
Med 500 17.9 13.4 – 16.70 – – – – – –
Low 500 16.0 12.6 – 29.65 12.1 – – – 4.00 –
CH16B2421S TM8V080C16MP12C 21.0 CF/CM30C
High 900 24.0 18.6 17.00 11.75 24.0 15.1 9.00 7.40 3.56 2.62
Med 625 18.2 14.9 – 16.75 ––––––
Low 625 16.4 14.2 – 29.65 12.3 – – – 4.16 –
CH16B2421S TM8V080C16MP12C 21.0 CF/CM36C
High 825 24.0 18.9 17.00 12.00 24.0 15.1 9.00 7.40 3.66 2.64
Med 700 18.7 15.4 – 16.70 – – – – – –
Low 700 16.5 14.8 – 28.45 12.5 – – – 4.14 –
CH16B2421S TM8V100C16MP12C 21.0 CF/CM24C
High 900 24.0 18.6 17.50 11.75 24.0 15.1 9.00 7.45 3.56 2.62
Med 500 17.9 13.4 – 16.70 ––––––
Low 500 16.0 12.6 – 29.65 12.1 – – – 4.00 –
CH16B2421S TM8V100C16MP12C 21.0 CF/CM30C
High 900 24.0 18.6 17.00 11.75 24.0 15.1 9.00 7.40 3.56 2.62
Med 625 18.2 14.9 – 16.75 – – – – – –
Low 625 16.4 14.2 – 29.65 12.3 – – – 4.16 –
CH16B2421S TM8V100C16MP12C 21.0 CF/CM36C
High 825 24.0 18.9 17.00 12.00 24.0 15.1 9.00 7.40 3.66 2.64
Med 700 18.7 15.4 – 16.70 ––––––
Low 700 16.5 14.8 – 28.45 12.5 – – – 4.14 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
