Coleman CH16B6021S - Page 16

5547666-CTG-A-0718
16 Johnson Controls Unitary Products
CH16B2421S TM9V060B12MP12C 17.5 CF/CM24B
High 800 24.0 18.6 17.25 11.25 24.0 15.2 9.00 7.45 3.60 2.62
Med 575 18.1 14.3 – 16.45 – – – – – –
Low 575 16.1 13.5 – 28.45 12.3 – – – 4.04 –
CH16B2421S TM9V060B12MP12C 17.5 CF/CM30B
High 800 24.0 18.7 16.75 11.25 24.0 15.4 9.00 7.45 3.52 2.56
Med 500 17.7 13.2 – 16.00 ––––––
Low 500 15.9 12.5 – 27.40 12.2 – – – 3.88 –
CH16B2421S TM9V060B12MP12C 17.5 CF/CM36B
High 875 24.0 19.2 17.25 11.25 24.0 14.9 9.00 7.45 3.76 2.70
Med 625 18.5 15.0 – 17.25 – – – – – –
Low 625 16.4 14.1 – 30.50 11.9 – – – 4.16 –
CH16B2421S TM9V060B12MP12C 17.5 CF24BBAA1
High 800 24.0 18.6 17.25 11.25 24.0 15.2 9.00 7.45 3.60 2.62
Med 575 18.1 14.3 – 16.45 ––––––
Low 575 16.1 13.5 – 28.45 12.3 – – – 4.04 –
CH16B2421S TM9V080B12MP12C 17.5 CF/CM24B
High 950 25.4 21.2 18.00 12.25 24.2 15.0 9.00 7.40 3.82 2.70
Med 650 18.6 15.2 – 17.35 – – – – – –
Low 650 16.4 14.4 – 30.60 12.0 – – – 4.20 –
CH16B2421S TM9V080B12MP12C 17.5 CF/CM30B
High 875 24.0 19.2 17.50 12.25 24.0 15.0 9.00 7.45 3.68 2.64
Med 625 18.5 14.8 – 17.00 ––––––
Low 625 16.4 14.1 – 29.70 12.0 – – – 4.10 –
CH16B2421S TM9V080B12MP12C 17.5 CF/CM36B
High 900 24.0 19.6 18.00 12.25 24.0 15.1 9.00 7.45 3.70 2.64
Med 650 18.5 15.1 – 17.05 – – – – – –
Low 650 16.4 14.4 – 29.80 12.1 – – – 4.14 –
CH16B2421S TM9V080B12MP12C 17.5 CF24BBAA1
High 950 25.4 21.2 18.00 12.25 24.2 15.0 9.00 7.40 3.82 2.70
Med 650 18.6 15.2 – 17.35 ––––––
Low 650 16.4 14.4 – 30.60 12.0 – – – 4.20 –
CH16B2421S TM9V080C16MP12C 21.0 CF/CM24C
High 675 24.0 17.7 17.50 12.00 24.0 14.8 9.00 7.45 3.54 2.66
Med 500 17.8 13.3 – 16.60 – – – – – –
Low 500 16.0 12.6 – 29.35 12.1 – – – 3.98 –
CH16B2421S TM9V080C16MP12C 21.0 CF/CM30C
High 750 24.0 18.1 17.50 12.00 24.0 14.9 9.00 7.45 3.62 2.66
Med 525 18.0 13.7 – 16.75 ––––––
Low 525 16.1 12.9 – 29.65 12.1 – – – 4.04 –
CH16B2421S TM9V080C16MP12C 21.0 CF/CM36C
High 850 24.0 19.0 17.50 12.00 24.0 15.1 9.00 7.45 3.70 2.66
Med 550 18.2 14.0 – 16.95 – – – – – –
Low 550 16.2 13.3 – 30.00 12.1 – – – 4.10 –
CH16B2421S TM9V100C16MP12C 21.0 CF/CM24C
High 900 24.0 19.7 17.50 12.25 24.0 15.1 9.00 7.45 3.72 2.66
Med 625 18.5 14.8 – 16.90 ––––––
Low 625 16.3 14.0 – 29.40 12.1 – – – 4.12 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
