Coleman CH16B6021S - Page 17

5547666-CTG-A-0718
Johnson Controls Unitary Products 17
CH16B2421S TM9V100C16MP12C 21.0 CF/CM30C
High 700 24.0 17.7 17.50 12.25 24.0 14.7 9.00 7.50 3.60 2.66
Med 600 18.3 14.5 – 16.70 – – – – – –
Low 600 16.3 13.6 – 29.15 12.0 – – – 4.08 –
CH16B2421S TM9V100C16MP12C 21.0 CF/CM36C
High 900 24.0 19.7 17.50 12.25 24.0 15.1 9.00 7.40 3.72 2.66
Med 750 18.8 16.2 – 16.85 ––––––
Low 750 16.5 15.6 – 28.80 12.4 – – – 4.20 –
CH16B2421S TM9Y040A10MP11 14.5 CF/CM24A
High 800 24.0 18.7 17.50 12.00 24.0 15.0 9.00 7.45 3.68 2.66
Med 525 18.0 13.7 – 16.80 – – – – – –
Low 525 16.1 12.9 – 29.80 12.1 – – – 4.06 –
CH16B2421S TM9Y040A10MP11 14.5 CF/CM30A
High 875 24.0 19.4 17.75 12.00 24.0 15.1 9.00 7.40 3.74 2.68
Med 625 18.4 15.0 – 17.00 ––––––
Low 625 16.4 14.2 – 29.95 12.3 – – – 4.18 –
CH16B2421S TM9Y040A10MP11 14.5 CF/CM36A
High 725 24.0 18.1 16.75 11.50 24.0 15.0 9.00 7.50 3.54 2.62
Med 500 17.8 13.3 – 16.30 – – – – – –
Low 500 16.0 12.6 – 28.35 12.1 – – – 3.92 –
CH16B2421S TM9Y040A10MP11 14.5 CF24ABAA1
High 800 24.0 18.7 17.50 12.00 24.0 15.0 9.00 7.45 3.68 2.66
Med 525 18.0 13.7 – 16.80 ––––––
Low 525 16.1 12.9 – 29.80 12.1 – – – 4.06 –
CH16B2421S TM9Y040A10MP11 14.5 CF30ABAA1
High 875 24.0 19.4 17.75 12.00 24.0 15.1 9.00 7.40 3.74 2.68
Med 625 18.4 15.0 – 17.00 – – – – – –
Low 625 16.4 14.2 – 29.95 12.3 – – – 4.18 –
CH16B2421S TM9Y060B12MP11 17.5 CF/CM24B
High 675 24.0 17.7 17.25 11.75 24.0 14.9 9.00 7.50 3.50 2.62
Med 500 17.8 13.3 – 16.30 ––––––
Low 500 16.0 12.6 – 28.45 12.1 – – – 3.94 –
CH16B2421S TM9Y060B12MP11 17.5 CF/CM30B
High 900 24.0 18.6 17.25 11.25 24.0 15.3 9.00 7.40 3.48 2.56
Med 600 18.2 14.5 – 16.50 – – – – – –
Low 600 16.2 13.7 – 28.35 12.3 – – – 4.06 –
CH16B2421S TM9Y060B12MP11 17.5 CF/CM36B
High 875 24.0 19.2 17.25 11.75 24.0 14.8 9.00 7.45 3.78 2.70
Med 600 18.4 14.6 – 17.40 ––––––
Low 600 16.4 13.7 – 31.25 11.9 – – – 4.14 –
CH16B2421S TM9Y060B12MP11 17.5 CF24BBAA1
High 675 24.0 17.7 17.25 11.75 24.0 14.9 9.00 7.50 3.50 2.62
Med 500 17.8 13.3 – 16.30 – – – – – –
Low 500 16.0 12.6 – 28.45 12.1 – – – 3.94 –
CH16B2421S TM9Y080B12MP11 17.5 CF/CM24B
High 825 24.0 18.9 16.50 11.75 24.0 15.2 9.00 7.45 3.62 2.62
Med 550 18.1 13.9 – 16.45 ––––––
Low 550 16.1 13.2 – 28.40 12.2 – – – 4.00 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
