5547666-CTG-A-0718
18 Johnson Controls Unitary Products
CH16B2421S TM9Y080B12MP11 17.5 CF/CM30B
High 775 24.0 18.4 16.50 11.75 24.0 15.0 9.00 7.40 3.62 2.64
Med 675 18.5 15.4 – 16.55 – – – – – –
Low 675 16.3 14.7 – 28.00 12.5 – – – 4.12 –
CH16B2421S TM9Y080B12MP11 17.5 CF/CM36B
High 875 24.0 19.4 16.50 11.75 24.0 15.3 9.00 7.40 3.64 2.60
Med 700 18.6 15.3 – 16.35 ––––––
Low 700 16.5 14.8 – 27.40 12.6 – – – 4.08 –
CH16B2421S TM9Y080B12MP11 17.5 CF24BBAA1
High 825 24.0 18.9 16.50 11.75 24.0 15.2 9.00 7.45 3.62 2.62
Med 550 18.1 13.9 – 16.45 – – – – – –
Low 550 16.1 13.2 – 28.40 12.2 – – – 4.00 –
CH16B2421S TMLV060A12MP12C 14.5 CF/CM24A
High 800 24.0 18.6 17.25 11.75 24.0 15.0 9.00 7.50 3.56 2.60
Med 575 18.2 14.2 – 16.60 ––––––
Low 575 16.1 13.3 – 28.55 12.0 – – – 3.96 –
CH16B2421S TMLV060A12MP12C 14.5 CF/CM30A
High 650 24.0 17.4 16.75 11.75 24.0 14.8 8.75 7.30 3.40 2.56
Med 450 17.4 12.5 – 15.90 – – – – – –
Low 450 15.7 11.7 – 27.55 11.7 – – – 3.74 –
CH16B2421S TMLV060A12MP12C 14.5 CF/CM36A
High 925 24.6 19.3 18.00 12.00 24.6 15.0 9.00 7.40 3.64 2.66
Med 650 18.5 15.3 – 17.15 ––––––
Low 650 16.4 14.5 – 30.35 12.3 – – – 4.24 –
CH16B2421S TMLV060A12MP12C 14.5 CF24ABAA1
High 800 24.0 18.6 17.25 11.75 24.0 15.0 9.00 7.50 3.56 2.60
Med 575 18.2 14.2 – 16.60 – – – – – –
Low 575 16.1 13.3 – 28.55 12.0 – – – 3.96 –
CH16B2421S TMLV060A12MP12C 14.5 CF30ABAA1
High 650 24.0 17.4 16.75 11.75 24.0 14.8 8.75 7.30 3.40 2.56
Med 450 17.4 12.5 – 15.90 ––––––
Low 450 15.7 11.7 – 27.55 11.7 – – – 3.74 –
CH16B2421S TMLV080B12MP12C 17.5 CF/CM24B
High 875 24.0 19.5 17.75 12.00 24.0 15.1 9.00 7.40 3.72 2.66
Med 625 18.4 15.0 – 16.85 – – – – – –
Low 625 16.4 14.2 – 29.40 12.3 – – – 4.16 –
CH16B2421S TMLV080B12MP12C 17.5 CF/CM30B
High 775 24.0 18.4 17.75 12.00 24.0 15.0 9.00 7.45 3.64 2.66
Med 625 18.5 15.1 – 16.90 ––––––
Low 625 16.4 14.2 – 29.45 12.3 – – – 4.14 –
CH16B2421S TMLV080B12MP12C 17.5 CF/CM36B
High 800 24.0 18.7 17.75 12.00 24.0 15.0 9.00 7.45 3.66 2.66
Med 625 18.5 15.0 – 16.90 – – – – – –
Low 625 16.4 14.2 – 29.55 12.3 – – – 4.16 –
CH16B2421S TMLV080B12MP12C 17.5 CF24BBAA1
High 875 24.0 19.5 17.75 12.00 24.0 15.1 9.00 7.40 3.72 2.66
Med 625 18.4 15.0 – 16.85 ––––––
Low 625 16.4 14.2 – 29.40 12.3 – – – 4.16 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
