Johnson Controls Unitary Products 19
CH16B2421S TMLV080C16MP12C 21.0 CF/CM24C
High 900 24.0 18.6 17.50 11.75 24.0 15.1 9.00 7.45 3.56 2.62
Med 500 17.9 13.4 – 16.70 – – – – – –
Low 500 16.0 12.6 – 29.65 12.1 – – – 4.00 –
CH16B2421S TMLV080C16MP12C 21.0 CF/CM30C
High 900 24.0 18.6 17.00 11.75 24.0 15.1 9.00 7.40 3.56 2.62
Med 625 18.2 14.9 – 16.75 ––––––
Low 625 16.4 14.2 – 29.65 12.3 – – – 4.16 –
CH16B2421S TMLV080C16MP12C 21.0 CF/CM36C
High 825 24.0 18.9 17.00 12.00 24.0 15.1 9.00 7.40 3.66 2.64
Med 700 18.7 15.4 – 16.70 – – – – – –
Low 700 16.5 14.8 – 28.45 12.5 – – – 4.14 –
CH16B2421S TMLV100C16MP12C 21.0 CF/CM24C
High 900 24.0 18.6 17.50 11.75 24.0 15.1 9.00 7.45 3.56 2.62
Med 500 17.9 13.4 – 16.70 ––––––
Low 500 16.0 12.6 – 29.65 12.1 – – – 4.00 –
CH16B2421S TMLV100C16MP12C 21.0 CF/CM30C
High 900 24.0 18.6 17.00 11.75 24.0 15.1 9.00 7.40 3.56 2.62
Med 625 18.2 14.9 – 16.75 – – – – – –
Low 625 16.4 14.2 – 29.65 12.3 – – – 4.16 –
CH16B2421S TMLV100C16MP12C 21.0 CF/CM36C
High 825 24.0 18.9 17.00 12.00 24.0 15.1 9.00 7.40 3.66 2.64
Med 700 18.7 15.4 – 16.70 ––––––
Low 700 16.5 14.8 – 28.45 12.5 – – – 4.14 –
CH16B2421S TMLX060A12MP11 14.5 CF/CM24A
High 850 24.0 19.0 17.00 12.00 24.0 15.1 9.00 7.45 3.68 2.64
Med 600 18.4 14.5 – 16.85 – – – – – –
Low 600 16.2 13.7 – 29.10 12.0 – – – 4.04 –
CH16B2421S TMLX060A12MP11 14.5 CF/CM30A
High 800 24.0 18.5 17.00 12.25 24.0 14.9 9.00 7.50 3.64 2.64
Med 550 18.0 14.1 – 16.60 ––––––
Low 550 16.1 13.0 – 29.10 11.9 – – – 3.98 –
CH16B2421S TMLX060A12MP11 14.5 CF/CM36A
High 700 24.0 17.6 17.00 12.00 24.0 14.8 8.75 7.25 3.58 2.66
Med 475 17.7 13.0 – 16.55 – – – – – –
Low 475 16.0 12.3 – 29.45 12.0 – – – 3.94 –
CH16B2421S TMLX060A12MP11 14.5 CF24ABAA1
High 850 24.0 19.0 17.00 12.00 24.0 15.1 9.00 7.45 3.68 2.64
Med 600 18.4 14.5 – 16.85 ––––––
Low 600 16.2 13.7 – 29.10 12.0 – – – 4.04 –
CH16B2421S TMLX060A12MP11 14.5 CF30ABAA1
High 800 24.0 18.5 17.00 12.25 24.0 14.9 9.00 7.50 3.64 2.64
Med 550 18.0 14.1 – 16.60 – – – – – –
Low 550 16.1 13.0 – 29.10 11.9 – – – 3.98 –
CH16B2421S TMLX080B12MP11 17.5 CF/CM24B
High 575 24.0 16.5 16.50 12.00 24.0 14.6 8.75 7.30 3.40 2.64
Med 425 17.4 12.3 – 16.25 ––––––
Low 425 15.7 11.6 – 28.75 11.9 – – – 3.82 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
