Coleman CH16B6021S - Page 20

5547666-CTG-A-0718
20 Johnson Controls Unitary Products
CH16B2421S TMLX080B12MP11 17.5 CF/CM30B
High 725 24.0 18.1 17.00 12.00 24.0 14.8 9.00 7.50 3.60 2.66
Med 475 17.7 13.0 – 16.55 – – – – – –
Low 475 15.9 12.3 – 29.35 12.0 – – – 3.94 –
CH16B2421S TMLX080B12MP11 17.5 CF/CM36B
High 700 24.0 17.6 16.50 12.00 24.0 14.8 9.00 7.50 3.58 2.66
Med 475 17.7 13.0 – 16.55 ––––––
Low 475 16.0 12.3 – 29.45 12.0 – – – 3.94 –
CH16B2421S TMLX080B12MP11 17.5 CF24BBAA1
High 575 24.0 16.5 16.50 12.00 24.0 14.6 8.75 7.30 3.40 2.64
Med 425 17.4 12.3 – 16.25 – – – – – –
Low 425 15.7 11.6 – 28.75 11.9 – – – 3.82 –
CH16B2421S TP9C060B12MP13C 17.5 CF/CM24B
High 800 24.0 18.6 17.25 11.25 24.0 15.2 9.00 7.45 3.60 2.62
Med 575 18.1 14.3 – 16.45 ––––––
Low 575 16.1 13.5 – 28.45 12.3 – – – 4.04 –
CH16B2421S TP9C060B12MP13C 17.5 CF/CM30B
High 800 24.0 18.7 16.75 11.25 24.0 15.4 9.00 7.45 3.52 2.56
Med 500 17.7 13.2 – 16.00 – – – – – –
Low 500 15.9 12.5 – 27.40 12.2 – – – 3.88 –
CH16B2421S TP9C060B12MP13C 17.5 CF/CM36B
High 875 24.0 19.2 17.25 11.25 24.0 14.9 9.00 7.45 3.76 2.70
Med 625 18.5 15.0 – 17.25 ––––––
Low 625 16.4 14.1 – 30.50 11.9 – – – 4.16 –
CH16B2421S TP9C060B12MP13C 17.5 CF24BBAA1
High 800 24.0 18.6 17.25 11.25 24.0 15.2 9.00 7.45 3.60 2.62
Med 575 18.1 14.3 – 16.45 – – – – – –
Low 575 16.1 13.5 – 28.45 12.3 – – – 4.04 –
CH16B2421S TP9C080B12MP13C 17.5 CF/CM24B
High 950 25.4 21.2 18.00 12.25 24.2 15.0 9.00 7.40 3.82 2.70
Med 650 18.6 15.2 – 17.35 ––––––
Low 650 16.4 14.4 – 30.60 12.0 – – – 4.20 –
CH16B2421S TP9C080B12MP13C 17.5 CF/CM30B
High 875 24.0 19.2 17.50 12.25 24.0 15.0 9.00 7.45 3.68 2.64
Med 625 18.5 14.8 – 17.00 – – – – – –
Low 625 16.4 14.1 – 29.70 12.0 – – – 4.10 –
CH16B2421S TP9C080B12MP13C 17.5 CF/CM36B
High 900 24.0 19.6 18.00 12.25 24.0 15.1 9.00 7.45 3.70 2.64
Med 650 18.5 15.1 – 17.05 ––––––
Low 650 16.4 14.4 – 29.80 12.1 – – – 4.14 –
CH16B2421S TP9C080B12MP13C 17.5 CF24BBAA1
High 950 25.4 21.2 18.00 12.25 24.2 15.0 9.00 7.40 3.82 2.70
Med 650 18.6 15.2 – 17.35 – – – – – –
Low 650 16.4 14.4 – 30.60 12.0 – – – 4.20 –
CH16B2421S TP9C080C16MP13C 21.0 CF/CM24C
High 675 24.0 17.7 17.50 12.00 24.0 14.8 9.00 7.45 3.54 2.66
Med 500 17.8 13.3 – 16.60 ––––––
Low 500 16.0 12.6 – 29.35 12.1 – – – 3.98 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
