Coleman CH16B6021S - Page 7

5547666-CTG-A-0718
Johnson Controls Unitary Products 7
CH16B2421S MVC08BN21 17.5 CF/CM30B
High 825 24.0 19.1 17.25 11.75 24.0 15.1 9.00 7.45 3.58 2.60
Med 550 18.1 13.8 – 16.55 – – – – – –
Low 550 16.1 13.0 – 28.70 11.9 – – – 3.94 –
CH16B2421S MVC08BN21 17.5 CF/CM36B
High 850 24.0 19.2 17.25 12.00 24.0 15.0 9.00 7.45 3.64 2.62
Med 600 18.3 14.4 – 16.75 – – – – – –
Low 600 16.2 13.5 – 29.05 12.0 – – – 4.02 –
CH16B2421S MVC08BN21 17.5 CF24BBAA1
High 875 24.0 19.2 17.75 12.25 24.0 15.0 9.00 7.45 3.70 2.66
Med 625 18.5 14.8 – 17.15 – – – – – –
Low 625 16.4 14.1 – 30.10 12.0 – – – 4.12 –
CH16B2421S MVC12BN21 17.5 CF/CM24B
High 800 24.0 18.6 17.50 12.00 24.0 14.9 9.00 7.45 3.60 2.62
Med 550 18.1 13.8 – 16.65 – – – – – –
Low 550 16.1 13.0 – 29.10 11.9 – – – 3.96 –
CH16B2421S MVC12BN21 17.5 CF/CM30B
High 875 24.0 19.2 17.00 11.75 24.0 15.3 9.00 7.45 3.58 2.56
Med 650 18.4 15.0 – 16.45 – – – – – –
Low 650 16.3 14.3 – 27.85 12.2 – – – 4.00 –
CH16B2421S MVC12BN21 17.5 CF/CM36B
High 925 24.6 20.0 16.75 10.75 24.6 15.9 8.75 7.20 3.44 2.46
Med 550 18.0 13.8 – 16.10 – – – – – –
Low 550 16.0 12.9 – 27.40 12.0 – – – 3.84 –
CH16B2421S MVC12BN21 17.5 CF24BBAA1
High 800 24.0 18.6 17.50 12.00 24.0 14.9 9.00 7.45 3.60 2.62
Med 550 18.1 13.8 – 16.65 – – – – – –
Low 550 16.1 13.0 – 29.10 11.9 – – – 3.96 –
CH16B2421S MVC14DN21 24.5 CF/CM30D
High 950 25.2 21.0 16.25 10.50 25.4 16.1 8.75 7.25 3.38 2.40
Med 550 18.0 13.8 – 16.10 – – – – – –
Low 550 16.0 12.9 – 27.40 12.0 – – – 3.84 –
CH16B2421S MVC14DN21 24.5 CF/CM36D
High 950 25.2 21.0 15.00 10.25 25.4 16.1 8.75 7.20 3.38 2.40
Med 700 18.3 15.5 – 15.25 – – – – – –
Low 700 16.1 14.7 – 24.35 12.5 – – – 3.82 –
CH16B2421S MVC16CN21 21.0 CF/CM30C
High 725 24.0 18.0 17.25 11.75 24.0 14.8 9.00 7.50 3.52 2.60
Med 525 17.9 13.6 – 16.45 – – – – – –
Low 525 16.0 12.6 – 28.75 11.8 – – – 3.90 –
CH16B2421S MVC16CN21 21.0 CF/CM36C
High 900 24.0 19.6 17.25 11.50 24.0 15.3 9.00 7.45 3.60 2.58
Med 625 18.4 14.7 – 16.60 – – – – – –
Low 625 16.2 13.9 – 28.40 12.1 – – – 4.00 –
CH16B3621S AE36BX21 17.5 –
High 1225 34.8 25.8 16.75 11.25 35.0 22.2 10.00 8.50 3.50 2.72
Med 850 24.6 18.4 – 15.45 – – – – – –
Low 850 22.4 17.2 – 26.90 18.1 – – – 4.12 –
SYSTEM CAPACITY - Single Piece and Modular Air Handlers (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
Stage
RATED
CFM
COOLING
1
HEATING
2
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
