8 Johnson Controls Unitary Products
CH16B3621S AE36CX21 21.0 –
High 1275 34.8 28.8 16.50 10.50 35.2 22.6 9.50 8.00 3.54 2.66
Med 750 24.6 18.9 – 15.30 – – – – – –
Low 750 22.2 18.0 – 27.55 18.1 – – – 4.14 –
CH16B3621S AVC36BX21 17.5 –
High 1000 34.0 25.6 16.75 10.75 35.0 22.2 9.50 7.70 3.42 2.70
Med 675 23.8 17.8 – 15.25 – – – – – –
Low 675 21.8 16.9 – 28.80 18.1 – – – 4.04 –
CH16B3621S AVC36CX21 21.0 –
High 1175 34.8 27.8 16.75 11.00 35.0 22.2 9.75 8.00 3.56 2.72
Med 825 24.6 19.9 – 15.65 – – – – – –
Low 825 22.4 19.0 – 27.85 18.2 – – – 4.22 –
CH16B3621S AVC42CX21 21.0 –
High 1325 35.4 29.8 16.75 10.75 34.8 22.6 9.75 7.95 3.62 2.70
Med 825 24.6 19.8 – 15.70 – – – – – –
Low 825 22.4 19.0 – 27.60 18.1 – – – 4.26 –
CH16B3621S AVC48CX21 21.0 –
High 1275 35.2 29.2 17.00 11.00 34.8 22.4 9.75 8.20 3.66 2.74
Med 825 24.8 20.0 – 15.75 – – – – – –
Low 825 22.4 19.0 – 27.70 18.1 – – – 4.26 –
CH16B3621S AVC48DX21 24.5 –
High 1225 35.0 28.4 17.25 11.25 34.6 22.2 9.75 7.90 3.68 2.78
Med 800 24.6 19.6 – 15.80 – – – – – –
Low 800 22.4 18.7 – 28.25 18.0 – – – 4.28 –
CH16B3621S ME12BN21 17.5 CF/CM36B
High 1050 34.0 26.2 16.25 10.75 35.0 22.2 9.50 7.75 3.46 2.70
Med 875 24.6 20.4 – 15.45 – – – – – –
Low 875 22.6 19.7 – 26.90 18.4 – – – 4.16 –
CH16B3621S ME12BN21 17.5 CF36BBCA1
High 1050 34.0 26.2 16.25 10.75 35.0 22.2 9.50 7.75 3.46 2.70
Med 875 24.6 20.4 – 15.45 – – – – – –
Low 875 22.6 19.7 – 26.90 18.4 – – – 4.16 –
CH16B3621S ME12BN21 17.5 CF42B
High 1050 34.4 26.2 16.25 11.00 34.8 22.2 9.75 7.95 3.52 2.72
Med 875 24.8 20.6 – 15.65 – – – – – –
Low 875 22.4 19.6 – 26.85 18.3 – – – 4.20 –
CH16B3621S ME14DN21 24.5 CF/CM36D
High 1000 34.0 25.6 16.50 10.75 35.0 22.2 9.00 7.60 3.42 2.70
Med 700 24.0 18.0 – 15.25 – – – – – –
Low 700 21.8 17.2 – 28.60 18.1 – – – 4.04 –
CH16B3621S ME14DN21 24.5 CF/CM42D
High 975 33.8 25.2 16.50 10.75 34.6 22.0 9.00 7.55 3.48 2.72
Med 675 24.2 17.9 – 15.45 – – – – – –
Low 675 21.8 16.9 – 28.90 17.9 – – – 4.10 –
CH16B3621S ME14DN21 24.5 CF/CM48D
High 1025 34.2 25.8 17.00 11.25 34.4 22.0 9.75 7.85 3.58 2.78
Med 900 25.0 21.0 – 16.05 – – – – – –
Low 900 22.6 20.0 – 28.05 18.2 – – – 4.34 –
SYSTEM CAPACITY - Single Piece and Modular Air Handlers (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
Stage
RATED
CFM
COOLING
1
HEATING
2
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
