Coleman CH16B6021S - Page 9

5547666-CTG-A-0718
Johnson Controls Unitary Products 9
CH16B3621S MVC12BN21 17.5 CF42B
High 975 34.0 25.0 16.50 11.00 34.6 22.0 9.50 6.75 3.46 2.72
Med 675 24.2 17.8 – 15.55 – – – – – –
Low 675 21.8 16.9 – 28.95 18.0 – – – 4.08 –
CH16B3621S MVC14DN21 24.5 CF/CM42D
High 1325 35.4 29.8 17.00 11.25 35.0 22.2 9.75 7.90 3.64 2.76
Med 850 25.0 20.4 – 16.15 – – – – – –
Low 850 22.6 19.4 – 28.70 17.9 – – – 4.30 –
CH16B3621S MVC14DN21 24.5 CF/CM48D
High 1100 35.0 27.0 17.00 11.50 34.6 21.8 9.75 7.90 3.60 2.80
Med 725 24.6 18.6 – 15.55 – – – – – –
Low 725 22.0 17.6 – 30.40 17.7 – – – 4.20 –
CH16B3621S MVC16CN21 21.0 CF/CM36C
High 1025 34.2 25.8 16.75 11.00 35.0 22.0 9.50 7.60 3.44 2.74
Med 700 24.2 18.3 – 15.50 – – – – – –
Low 700 22.0 17.4 – 29.45 17.9 – – – 4.08 –
CH16B3621S MVC16CN21 21.0 CF/CM42C
High 1025 34.4 26.0 16.75 11.25 34.8 21.8 9.75 8.05 3.50 2.76
Med 700 24.4 18.2 – 15.60 – – – – – –
Low 700 21.8 17.2 – 29.50 17.8 – – – 4.12 –
CH16B3621S MVC16CN21 21.0 CF42CBCA1
High 1025 34.4 26.0 16.75 11.25 34.8 21.8 9.75 8.05 3.50 2.76
Med 700 24.4 18.2 – 15.60 – – – – – –
Low 700 21.8 17.2 – 29.50 17.8 – – – 4.12 –
CH16B3621S MVC20DN21 24.5 CF/CM36D
High 1275 35.4 29.4 17.00 11.25 35.0 22.0 9.75 7.85 3.44 2.72
Med 875 24.8 20.6 – 16.00 – – – – – –
Low 875 22.6 19.7 – 28.60 18.0 – – – 4.28 –
CH16B3621S MVC20DN21 24.5 CF/CM42D
High 1300 35.4 29.6 17.25 11.25 34.8 22.0 9.75 7.80 3.64 2.78
Med 900 25.0 21.0 – 16.25 – – – – – –
Low 900 22.6 20.0 – 28.65 18.0 – – – 4.34 –
CH16B3621S MVC20DN21 24.5 CF/CM48D
High 1300 35.6 29.6 17.00 11.50 34.6 22.0 9.75 7.75 3.68 2.80
Med 900 25.0 21.0 – 16.20 – – – – – –
Low 900 22.8 20.2 – 28.65 17.9 – – – 4.36 –
CH16B4821S AE48CBC21 21.0 –
High 1425 47.0 31.8 16.70 10.20 47.0 28.4 9.70 8.10 3.22 2.56
Med 1050 33.4 23.2 – 15.30 – – – – – –
Low 1075 28.0 21.6 – 27.00 22.2 – – – 4.20 –
CH16B4821S AE48CX21 21.0 –
High 1425 47.0 31.8 16.70 10.20 47.0 28.4 9.70 8.10 3.22 2.56
Med 1050 33.4 23.2 – 15.30 – – – – – –
Low 1075 28.0 21.6 – 27.00 22.2 – – – 4.20 –
CH16B4821S AE48DBC21 24.5 –
High 1675 47.0 35.8 17.00 9.75 48.0 28.2 9.50 7.70 3.16 2.54
Med 1125 33.8 27.4 – 15.85 – – – – – –
Low 1125 28.2 24.6 – 28.60 22.2 – – – 4.36 –
SYSTEM CAPACITY - Single Piece and Modular Air Handlers (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
Stage
RATED
CFM
COOLING
1
HEATING
2
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
