Johnson Controls Unitary Products 71
CH16B4821S TMLX080C16MP11 21.0 CF/CM60D
High 1400 47.5 35.2 16.50 9.75 47.5 28.6 9.50 7.85 3.22 2.60
Med 825 32.2 22.8 – 15.50 – – – – – –
Low 825 27.2 21.2 – 28.25 21.4 – – – 4.12 –
CH16B4821S TMLX080C16MP11 21.0 CF/CM64D
High 1375 48.0 35.2 16.50 9.75 46.5 29.4 9.50 7.90 3.32 2.72
Med 800 32.4 22.8 – 15.60 ––––––
Low 800 27.0 20.6 – 28.20 20.2 – – – 4.08 –
CH16B4821S TMLX080C16MP11 21.0 CF48CBCA1
High 1550 46.0 34.0 16.50 9.25 48.0 28.6 9.25 7.55 3.04 2.44
Med 825 32.4 23.0 – 15.50 – – – – – –
Low 825 27.4 21.0 – 28.50 21.8 – – – 4.10 –
CH16B4821S TMLX100C16MP11 21.0 CF/CM48C
High 1550 46.0 34.0 16.50 9.25 48.0 28.6 9.25 7.55 3.04 2.44
Med 825 32.4 23.0 – 15.50 ––––––
Low 825 27.4 21.0 – 28.50 21.8 – – – 4.10 –
CH16B4821S TMLX100C16MP11 21.0 CF/CM48D
High 1575 46.0 34.2 16.50 9.25 48.0 28.6 9.25 7.55 3.04 2.46
Med 825 32.4 23.0 – 15.50 – – – – – –
Low 825 27.4 21.0 – 28.45 21.8 – – – 4.10 –
CH16B4821S TMLX100C16MP11 21.0 CF/CM60C
High 1375 47.5 35.0 16.50 9.75 47.5 28.4 9.50 7.85 3.20 2.58
Med 800 32.2 22.6 – 15.45 ––––––
Low 800 27.0 20.4 – 28.15 21.4 – – – 4.08 –
CH16B4821S TMLX100C16MP11 21.0 CF/CM60D
High 1400 47.5 35.2 16.50 9.75 47.5 28.6 9.50 7.85 3.22 2.60
Med 825 32.2 22.8 – 15.50 – – – – – –
Low 825 27.2 21.2 – 28.25 21.4 – – – 4.12 –
CH16B4821S TMLX100C16MP11 21.0 CF/CM64D
High 1375 48.0 35.2 16.50 9.75 46.5 29.4 9.50 7.90 3.32 2.72
Med 800 32.4 22.8 – 15.60 ––––––
Low 800 27.0 20.6 – 28.20 20.2 – – – 4.08 –
CH16B4821S TMLX100C16MP11 21.0 CF48CBCA1
High 1550 46.0 34.0 16.50 9.25 48.0 28.6 9.25 7.55 3.04 2.44
Med 825 32.4 23.0 – 15.50 – – – – – –
Low 825 27.4 21.0 – 28.50 21.8 – – – 4.10 –
CH16B4821S TMLX100C20MP11 21.0 CF/CM48C
High 1375 47.0 34.6 16.50 9.75 48.0 28.2 9.50 7.75 3.18 2.56
Med 1050 33.4 25.8 – 15.45 ––––––
Low 1050 27.6 23.8 – 27.00 22.2 – – – 4.22 –
CH16B4821S TMLX100C20MP11 21.0 CF/CM48D
High 1575 46.5 34.6 16.50 9.50 48.0 28.4 9.50 7.75 3.08 2.48
Med 1075 33.6 26.4 – 15.50 – – – – – –
Low 1075 28.0 24.4 – 27.30 22.2 – – – 4.24 –
CH16B4821S TMLX100C20MP11 21.0 CF/CM60C
High 1375 47.5 35.0 16.50 9.75 47.5 28.4 9.50 7.80 3.22 2.60
Med 1050 33.4 25.6 – 15.45 ––––––
Low 1050 27.8 23.8 – 27.05 22.0 – – – 4.22 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
To Next Page
