72 Johnson Controls Unitary Products
CH16B4821S TMLX100C20MP11 21.0 CF/CM60D
High 1600 48.0 37.6 16.50 9.75 48.0 29.2 9.50 7.80 3.30 2.62
Med 1075 33.6 26.2 – 15.60 – – – – – –
Low 1075 27.8 23.8 – 27.35 22.0 – – – 4.26 –
CH16B4821S TMLX100C20MP11 21.0 CF/CM64D
High 1375 48.0 35.4 16.50 9.75 46.0 29.2 9.75 8.15 3.34 2.74
Med 1050 33.6 26.2 – 15.70 ––––––
Low 1050 27.6 23.8 – 27.10 21.0 – – – 4.24 –
CH16B4821S TMLX100C20MP11 21.0 CF48CBCA1
High 1375 47.0 34.6 16.50 9.75 48.0 28.2 9.50 7.75 3.18 2.56
Med 1050 33.4 25.8 – 15.45 – – – – – –
Low 1050 27.6 23.8 – 27.00 22.2 – – – 4.22 –
CH16B4821S TMLX120C20MP11 21.0 CF/CM48C
High 1375 47.0 34.6 16.50 9.75 48.0 28.2 9.50 7.75 3.18 2.56
Med 1050 33.4 25.8 – 15.45 ––––––
Low 1050 27.6 23.8 – 27.00 22.2 – – – 4.22 –
CH16B4821S TMLX120C20MP11 21.0 CF/CM48D
High 1575 46.5 34.6 16.50 9.50 48.0 28.4 9.50 7.75 3.08 2.48
Med 1075 33.6 26.4 – 15.50 – – – – – –
Low 1075 28.0 24.4 – 27.30 22.2 – – – 4.24 –
CH16B4821S TMLX120C20MP11 21.0 CF/CM60C
High 1375 47.5 35.0 16.50 9.75 47.5 28.4 9.50 7.80 3.22 2.60
Med 1050 33.4 25.6 – 15.45 ––––––
Low 1050 27.8 23.8 – 27.05 22.0 – – – 4.22 –
CH16B4821S TMLX120C20MP11 21.0 CF/CM60D
High 1600 48.0 37.6 16.50 9.75 48.0 29.2 9.50 7.80 3.30 2.62
Med 1075 33.6 26.2 – 15.60 – – – – – –
Low 1075 27.8 23.8 – 27.35 22.0 – – – 4.26 –
CH16B4821S TMLX120C20MP11 21.0 CF/CM64D
High 1375 48.0 35.4 16.50 9.75 46.0 29.2 9.75 8.15 3.34 2.74
Med 1050 33.6 26.2 – 15.70 ––––––
Low 1050 27.6 23.8 – 27.10 21.0 – – – 4.24 –
CH16B4821S TMLX120C20MP11 21.0 CF48CBCA1
High 1375 47.0 34.6 16.50 9.75 48.0 28.2 9.50 7.75 3.18 2.56
Med 1050 33.4 25.8 – 15.45 – – – – – –
Low 1050 27.6 23.8 – 27.00 22.2 – – – 4.22 –
CH16B4821S TP9C060B12MP13C 17.5 CF/CM48C
High 1225 45.5 32.4 15.75 9.25 48.0 28.4 9.00 7.05 3.02 2.42
Med 750 31.4 21.6 – 14.60 ––––––
Low 750 26.8 19.7 – 26.35 21.8 – – – 3.86 –
CH16B4821S TP9C060B12MP13C 17.5 CF/CM60C
High 1225 46.0 32.6 15.75 9.25 48.0 28.6 9.25 7.35 3.06 2.48
Med 750 31.4 21.4 – 14.70 – – – – – –
Low 750 26.6 19.6 – 26.10 21.4 – – – 3.84 –
CH16B4821S TP9C060B12MP13C 17.5 CF48CBCA1
High 1225 45.5 32.4 15.75 9.25 48.0 28.4 9.00 7.05 3.02 2.42
Med 750 31.4 21.6 – 14.60 ––––––
Low 750 26.8 19.7 – 26.35 21.8 – – – 3.86 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
To Next Page
