Johnson Controls Unitary Products 73
CH16B4821S TP9C080B12MP13C 17.5 CF/CM48C
High 1250 46.0 32.8 16.00 9.50 48.0 28.2 9.25 7.15 3.08 2.46
Med 825 32.0 22.8 – 14.85 – – – – – –
Low 825 27.2 20.8 – 26.65 22.0 – – – 3.96 –
CH16B4821S TP9C080B12MP13C 17.5 CF/CM60C
High 1250 46.5 33.2 16.00 9.50 47.5 28.4 9.25 7.20 3.10 2.52
Med 825 32.0 22.6 – 14.85 ––––––
Low 825 27.0 20.8 – 26.45 21.6 – – – 3.94 –
CH16B4821S TP9C080B12MP13C 17.5 CF48CBCA1
High 1250 46.0 32.8 16.00 9.50 48.0 28.2 9.25 7.15 3.08 2.46
Med 825 32.0 22.8 – 14.85 – – – – – –
Low 825 27.2 20.8 – 26.65 22.0 – – – 3.96 –
CH16B4821S TP9C080C16MP13C 21.0 CF/CM48C
High 1300 46.5 33.6 16.00 9.50 48.0 28.2 9.25 7.20 3.12 2.48
Med 875 32.4 23.4 – 15.00 ––––––
Low 875 27.4 21.6 – 26.70 22.0 – – – 4.02 –
CH16B4821S TP9C080C16MP13C 21.0 CF/CM48D
High 1300 46.5 33.8 16.00 9.50 48.0 28.2 9.25 7.10 3.12 2.50
Med 875 32.4 23.4 – 15.00 – – – – – –
Low 875 27.4 21.6 – 26.75 22.0 – – – 4.02 –
CH16B4821S TP9C080C16MP13C 21.0 CF/CM60C
High 1225 46.5 33.0 16.00 9.75 47.5 28.2 9.25 7.20 3.12 2.54
Med 800 32.0 22.4 – 15.00 ––––––
Low 800 26.8 20.2 – 26.75 21.4 – – – 3.94 –
CH16B4821S TP9C080C16MP13C 21.0 CF/CM60D
High 1300 47.0 33.8 16.00 9.75 47.5 28.4 9.25 7.35 3.16 2.56
Med 875 32.2 23.4 – 15.05 – – – – – –
Low 875 27.2 21.2 – 26.65 21.6 – – – 4.00 –
CH16B4821S TP9C080C16MP13C 21.0 CF/CM64D
High 1375 48.0 35.4 16.00 9.75 46.5 29.8 9.50 7.65 3.30 2.68
Med 900 32.6 24.2 – 15.15 ––––––
Low 900 27.0 21.6 – 26.40 20.8 – – – 4.00 –
CH16B4821S TP9C080C16MP13C 21.0 CF48CBCA1
High 1300 46.5 33.6 16.00 9.50 48.0 28.2 9.25 7.20 3.12 2.48
Med 875 32.4 23.4 – 15.00 – – – – – –
Low 875 27.4 21.6 – 26.70 22.0 – – – 4.02 –
CH16B4821S TP9C100C16MP13C 21.0 CF/CM48C
High 1275 46.5 33.4 16.25 9.75 48.0 28.0 9.25 7.10 3.14 2.52
Med 875 32.4 23.4 – 15.15 ––––––
Low 875 27.4 21.6 – 27.25 22.0 – – – 4.04 –
CH16B4821S TP9C100C16MP13C 21.0 CF/CM48D
High 1275 46.5 33.4 16.25 9.75 48.0 28.0 9.25 7.10 3.14 2.52
Med 875 32.4 23.4 – 15.15 – – – – – –
Low 875 27.4 21.6 – 27.30 22.0 – – – 4.06 –
CH16B4821S TP9C100C16MP13C 21.0 CF/CM60C
High 1325 47.5 34.4 16.25 9.75 47.5 28.4 9.50 7.50 3.20 2.58
Med 925 32.6 24.0 – 15.15 ––––––
Low 925 27.4 21.8 – 27.00 21.6 – – – 4.06 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
