Coleman CH16B6021S - Page 86

5547666-CTG-A-0718
86 Johnson Controls Unitary Products
CH16B6021S TM8Y100C20MP11 21.0 CF/CM60D
High 1400 55.0 38.5 15.75 9.75 60.0 33.2 8.75 7.15 2.76 2.30
Med 1050 36.4 27.4 – 14.60 – – – – – –
Low 1050 31.0 24.8 – 26.15 26.2 – – – 3.84 –
CH16B6021S TM8Y100C20MP11 21.0 CF/CM64D
High 1375 55.5 38.5 15.75 10.00 58.5 32.2 9.25 7.60 3.34 2.72
Med 1050 36.4 27.4 – 14.70 ––––––
Low 1050 30.8 25.0 – 26.20 25.4 – – – 4.16 –
CH16B6021S TM8Y120C20MP11 21.0 CF/CM48C
High 1550 52.5 36.6 15.75 9.25 60.0 34.4 8.50 6.90 2.72 2.10
Med 1050 36.2 27.0 – 14.60 – – – – – –
Low 1050 30.8 25.0 – 26.00 26.4 – – – 3.78 –
CH16B6021S TM8Y120C20MP11 21.0 CF/CM48D
High 1575 53.0 37.2 15.75 9.50 60.0 34.4 8.50 6.85 2.68 2.12
Med 1075 36.4 27.4 – 14.65 ––––––
Low 1075 30.8 25.2 – 26.15 26.4 – – – 3.80 –
CH16B6021S TM8Y120C20MP11 21.0 CF/CM60C
High 1375 54.5 37.8 15.75 9.75 60.0 33.4 8.75 7.15 2.76 2.26
Med 1050 36.4 27.4 – 14.55 – – – – – –
Low 1050 31.0 24.8 – 26.05 26.2 – – – 3.82 –
CH16B6021S TM8Y120C20MP11 21.0 CF/CM60D
High 1400 55.0 38.5 15.75 9.75 60.0 33.2 8.75 7.15 2.76 2.30
Med 1050 36.4 27.4 – 14.60 ––––––
Low 1050 31.0 24.8 – 26.15 26.2 – – – 3.84 –
CH16B6021S TM8Y120C20MP11 21.0 CF/CM64D
High 1375 55.5 38.5 15.75 10.00 58.5 32.2 9.25 7.60 3.34 2.72
Med 1050 36.4 27.4 – 14.70 – – – – – –
Low 1050 30.8 25.0 – 26.20 25.4 – – – 4.16 –
CH16B6021S TM9E100C20MP11 21.0 CF/CM48C
High 1525 54.0 39.0 14.50 9.50 60.0 34.6 8.50 6.40 2.72 2.10
Med 1400 37.2 31.2 – 13.80 ––––––
Low 1400 31.4 28.6 – 22.85 27.0 – – – 3.62 –
CH16B6021S TM9E100C20MP11 21.0 CF/CM48D
High 1550 52.5 36.6 15.00 9.25 60.0 34.6 8.50 6.80 2.72 2.10
Med 1225 36.6 29.4 – 14.15 – – – – – –
Low 1225 31.0 27.0 – 24.25 26.6 – – – 3.78 –
CH16B6021S TM9E100C20MP11 21.0 CF/CM60C
High 1525 55.0 39.5 15.00 9.50 60.0 33.6 8.75 7.10 2.96 2.34
Med 1225 36.8 29.0 – 14.20 ––––––
Low 1225 31.0 26.6 – 24.25 26.4 – – – 3.88 –
CH16B6021S TM9E100C20MP11 21.0 CF/CM60D
High 1850 54.0 40.0 15.00 9.00 60.0 34.4 8.75 7.05 2.88 2.26
Med 1250 37.0 29.4 – 14.30 – – – – – –
Low 1250 31.2 26.8 – 24.60 26.4 – – – 3.90 –
CH16B6021S TM9E100C20MP11 21.0 CF/CM64D
High 1550 56.0 40.5 15.00 9.75 59.0 32.6 9.00 7.30 3.38 2.68
Med 1225 37.4 29.8 – 14.50 ––––––
Low 1225 31.2 27.0 – 24.50 25.8 – – – 4.12 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
