Coleman CH16B6021S - Page 87

5547666-CTG-A-0718
Johnson Controls Unitary Products 87
CH16B6021S TM9E120D20MP11 24.5 CF/CM48D
High 1600 53.0 37.4 15.75 9.25 60.0 34.4 8.50 6.90 2.72 2.10
Med 1025 36.2 26.8 – 14.70 – – – – – –
Low 1025 30.8 24.6 – 26.40 26.4 – – – 3.80 –
CH16B6021S TM9E120D20MP11 24.5 CF/CM60D
High 1600 55.5 41.0 15.75 9.50 60.0 33.4 8.75 7.15 3.00 2.40
Med 1025 36.2 27.0 – 14.70 ––––––
Low 1025 30.8 24.4 – 26.50 26.0 – – – 3.92 –
CH16B6021S TM9E120D20MP11 24.5 CF/CM64D
High 1375 55.0 38.0 15.75 9.75 58.5 32.2 9.00 7.35 3.32 2.72
Med 1000 36.2 26.8 – 14.75 – – – – – –
Low 1000 30.6 24.2 – 26.35 25.4 – – – 4.14 –
CH16B6021S TM9V080C16MP12C 21.0 CF/CM48C
High 1375 53.5 37.2 15.25 9.50 60.0 34.2 8.50 6.45 2.74 2.14
Med 900 36.2 25.4 – 14.30 ––––––
Low 900 30.2 22.8 – 25.35 26.4 – – – 3.74 –
CH16B6021S TM9V080C16MP12C 21.0 CF/CM48D
High 1375 53.5 37.2 15.25 9.50 60.0 34.2 8.50 6.45 2.74 2.14
Med 900 36.2 25.4 – 14.30 – – – – – –
Low 900 30.2 22.8 – 25.45 26.4 – – – 3.74 –
CH16B6021S TM9V080C16MP12C 21.0 CF/CM60C
High 1525 55.0 39.5 15.25 9.50 60.0 34.0 8.75 6.70 2.94 2.30
Med 975 36.6 27.0 – 14.30 ––––––
Low 975 30.6 24.0 – 25.20 26.2 – – – 3.86 –
CH16B6021S TM9V080C16MP12C 21.0 CF/CM60D
High 1625 55.5 41.0 15.25 9.50 60.0 34.0 8.75 6.60 2.96 2.36
Med 1025 36.8 27.4 – 14.30 – – – – – –
Low 1025 30.8 24.6 – 25.05 26.2 – – – 3.82 –
CH16B6021S TM9V080C16MP12C 21.0 CF/CM64D
High 1375 55.0 38.5 15.50 9.75 59.0 32.6 9.25 7.30 3.28 2.66
Med 900 36.4 26.0 – 14.40 ––––––
Low 900 30.2 23.2 – 25.50 25.2 – – – 4.04 –
CH16B6021S TM9V100C16MP12C 21.0 CF/CM48C
High 1425 54.0 38.0 15.50 9.50 60.0 33.8 8.50 6.40 2.78 2.22
Med 975 36.6 26.4 – 14.45 – – – – – –
Low 975 30.6 24.0 – 25.65 26.2 – – – 3.76 –
CH16B6021S TM9V100C16MP12C 21.0 CF/CM48D
High 1425 54.0 38.0 15.50 9.75 60.0 33.6 8.50 6.40 2.78 2.24
Med 975 36.6 26.4 – 14.45 ––––––
Low 975 30.6 24.0 – 25.75 26.2 – – – 3.76 –
CH16B6021S TM9V100C16MP12C 21.0 CF/CM60C
High 1475 55.0 39.0 15.50 9.75 60.0 33.6 8.75 6.70 2.94 2.34
Med 1025 36.8 27.4 – 14.45 – – – – – –
Low 1025 30.8 24.6 – 25.45 26.0 – – – 3.84 –
CH16B6021S TM9V100C16MP12C 21.0 CF/CM60D
High 1600 55.5 41.0 15.50 9.75 60.0 33.6 8.75 6.65 2.98 2.38
Med 1100 37.2 28.4 – 14.50 ––––––
Low 1100 31.0 25.4 – 25.35 26.2 – – – 3.88 –
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
