Coleman CH16B6021S - Page 97

5547666-CTG-A-0718
Johnson Controls Unitary Products 97
CH16B6021S CPLC100C20MP13C 21.0 CF/CM48C
High 1375 53.5 37.0 15.75 9.75 60.0 33.6 8.50 6.45 2.78 2.18
Med 900 35.6 25.0 – 14.50 – – – – – –
Low 900 30.2 22.8 – 26.20 26.4 – – – 3.78 –
CH16B6021S CPLC100C20MP13C 21.0 CF/CM48D
High 1425 54.0 38.0 15.75 9.75 60.0 33.4 8.50 6.40 2.80 2.26
Med 975 36.0 26.2 – 14.60 ––––––
Low 975 30.6 24.0 – 26.20 26.2 – – – 3.80 –
CH16B6021S CPLC100C20MP13C 21.0 CF/CM60C
High 1375 54.5 37.8 15.75 9.75 60.0 33.4 8.50 6.35 2.76 2.26
Med 900 35.6 25.4 – 14.45 – – – – – –
Low 900 30.2 23.2 – 26.05 26.2 – – – 3.80 –
CH16B6021S CPLC100C20MP13C 21.0 CF/CM60D
High 1425 54.5 38.5 15.75 9.75 60.0 33.2 8.75 6.80 2.82 2.28
Med 975 36.0 26.4 – 14.55 ––––––
Low 975 30.6 24.2 – 26.25 26.2 – – – 3.88 –
CH16B6021S CPLC100C20MP13C 21.0 CF/CM64D
High 1450 55.5 39.0 15.75 10.00 58.5 32.4 9.25 7.25 3.40 2.72
Med 975 36.2 26.4 – 14.70 – – – – – –
Low 975 30.6 24.2 – 26.15 25.4 – – – 4.12 –
CH16B6021S CPLC120C20MP13C 21.0 CF/CM48C
High 1375 53.5 37.0 15.75 9.75 60.0 33.6 8.50 6.45 2.78 2.18
Med 900 35.6 25.0 – 14.50 ––––––
Low 900 30.2 22.8 – 26.20 26.4 – – – 3.78 –
CH16B6021S CPLC120C20MP13C 21.0 CF/CM48D
High 1425 54.0 38.0 15.75 9.75 60.0 33.4 8.50 6.40 2.80 2.26
Med 975 36.0 26.2 – 14.60 – – – – – –
Low 975 30.6 24.0 – 26.20 26.2 – – – 3.80 –
CH16B6021S CPLC120C20MP13C 21.0 CF/CM60C
High 1375 54.5 37.8 15.75 9.75 60.0 33.4 8.50 6.35 2.76 2.26
Med 900 35.6 25.4 – 14.45 ––––––
Low 900 30.2 23.2 – 26.05 26.2 – – – 3.80 –
CH16B6021S CPLC120C20MP13C 21.0 CF/CM60D
High 1425 54.5 38.5 15.75 9.75 60.0 33.2 8.75 6.80 2.82 2.28
Med 975 36.0 26.4 – 14.55 – – – – – –
Low 975 30.6 24.2 – 26.25 26.2 – – – 3.88 –
CH16B6021S CPLC120C20MP13C 21.0 CF/CM64D
High 1450 55.5 39.0 15.75 10.00 58.5 32.4 9.25 7.25 3.40 2.72
Med 975 36.2 26.4 – 14.70 ––––––
Low 975 30.6 24.2 – 26.15 25.4 – – – 4.12 –
1. High Efficiency Motor Furnaces have B.O.D. (Blower on Delay) standard.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
Stage
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF IV HSPF V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
