APPLICATION & ACCESSORIES
Refer to Price Manual for specific model numbers.
* For applications such as Low Ambient, reduced linesets, and/or long line-
sets, see the accessories listed below.
Support Feet S1-HPRKIT-**: Kit of 5 support feet to raise unit
above snow or landscaping. Available in heights of 3", 6" or 12".
Anchor Bracket Kit S1-1HK0401: Firmly anchors unit to pad
or support structure. When properly installed, approved for
ground-mounted or roof-mounted applications.
Indoor TXV Kit S1-1TVM***: Thermal expansion valves pre-
cisely meter refrigerant for optimum performance over a wide
range of conditions. See System Charge Table, Price Pages, or
Source1 Smart Search for TXV part number for each AC & HP
model.
Wall Mount Kit (S1-ACB-**): Includes two brackets to allow
outdoor unit to be securely mounted to a vertical wall. Mounting
hardware is field sourced according to the specific application.
Cold Weather Charging Tent S1-CHGTENT01: Provides
warm environment to accurately service AC & HP systems in
ambient conditions 55ºF (13ºC) or colder.
Touch-up Paint S1-5130153****: Color matched aerosol paint
for touching up unit chassis and panels. See Price Pages or
Source1 SmartSearch for the correct color for each application.
Thermostat: Compatible thermostat controls are available
through accessory sourcing. For optimum performance, these
outdoor units are fully compatible with our Coleman Hx™
Touchscreen Thermostats available through Source1. For more
information, see the thermostat section of the Product Equip-
ment Catalog.
Rated in accordance with ARI Standard 270.
Rated in accordance with ARI Standard 270.
Standard Application Limits*
Maximum Lineset Equivalent Length 80 Ft
Outdoor Ambient Temperature Limits
Cooling Operation
Maximum DB 115ºF
Minimum DB 35ºF
Heating Operation
Maximum DB 75ºF
Minimum DB -20ºF
SOUND POWER RATINGS - COOLING
High Stage Cooling Octave Band Sound Power Level (db re. 1-pW)
Model Number 63 125 250 500 1000 2000 4000 8000 dBA SQI
CH16B2421S 65 71 64 69 64 61 62 60 70 19.2
CH16B3621S 68 67 63 68 72 62 61 66 74 19.0
CH16B4821S 76 76 72 73 71 66 65 63 75 19.0
CH16B6021S 74 74 73 71 70 70 68 64 76 19.1
Low Stage Cooling Octave Band Sound Power Level (db re. 1-pW)
CH16B2421S 67 74 65 68 65 62 62 59 70 19.1
CH16B3621S 67 67 62 64 63 58 56 56 67 19.2
CH16B4821S 76 76 72 72 70 64 61 61 74 19.0
CH16B6021S 74 74 73 71 69 65 61 61 74 19.0
SOUND POWER RATINGS - HEATING
High Stage Heating Octave Band Sound Power Level (db re. 1-pW)
Model Number 63 125 250 500 1000 2000 4000 8000 dBA SQI
CH16B2421S 66 76 66 69 65 62 67 63 72 19.0
CH16B3621S 70 71 69 72 78 64 63 61 79 19.1
CH16B4821S 75 74 74 72 71 66 65 62 76 19.1
CH16B6021S 74 75 72 72 70 64 61 62 74 19.0
Low Stage Heating Octave Band Sound Power Level (db re. 1-pW)
CH16B2421S 67 75 66 68 64 61 60 58 70 19.0
CH16B3621S 70 70 68 69 66 61 59 59 71 19.0
CH16B4821S 76 73 73 72 71 64 60 59 74 19.0
CH16B6021S 75 75 72 71 70 63 60 62 74 19.1
