Coleman HC8B024F1 - Heating Capacity - With Air Handler

Unitary Products Group 7
345095-CTG-B-0907
** Refer to Quick Selection Chart for specific furnace match-up.
HEATING CAPACITY - With Air Handler
UNIT MODEL
AIR HANDLER
MODEL
COIL
1
MODEL
W
HEATING
STAGE
RATED
CFM
NET MBH
HSPF COP @ 47
47 OD 17 OD
18 SEER HP WITH MV - VARIABLE SPEED
HC8B024F1
MV12B FC/MC43B 17
1 645 19.3 - - 4.0
2 835 24.0 17.0 9.6 4.0
2 645 24.0 15.2 9.3 3.4
MV12D FC/MC48D 24
1 645 19.3 - - 4.0
2 835 24.0 16.8 9.8 4.0
2 645 24.0 15.0 9.5 3.4
MV12D FC/MC60D 24
1 645 19.3 - - 4.0
2 835 24.0 16.8 9.8 4.0
2 645 24.0 15.0 9.5 3.4
HC8B036F1
MV16C FC/MC43C 21
1 775 26.4 - - 4.2
2 1200 36.0 25.8 10 4.4
2 775 36.0 24.0 9.7 3.4
MV16C FC/MC48C 21
1 775 26.4 - - 4.2
2 1200 36.0 25.8 10 4.4
2 775 36.0 24.0 9.7 3.4
MV12D FC/MC48D 24
1 845 26.4 - - 4.2
2 1245 36.0 25.8 10 4.4
2 845 36.0 24.0 9.7 3.4
MV12D FC/MC60D 24
1 845 26.4 - - 4.2
2 1245 36.0 25.8 10 4.4
2 845 36.0 24.0 9.7 3.4
MV12D FC/MC62D 24
1 845 26.4 - - 4.2
2 1245 36.0 25.8 10 4.4
2 845 36.0 24.0 9.7 3.4
HC8B048F1
MV16C FC/MC48C 21
1 1000 35.6 - - 3.6
2 1600 48.0 32.6 9.3 3.8
2 1000 38.0 25.4 9 3.0
MV20D FC/MC48D 24
1 1045 36.0 - - 3.6
2 1570 48.0 32.6 9.3 3.8
2 1045 38.0 25.6 9 3.0
MV20D FC/MC60D 24
1 1045 36.0 - - 3.8
2 1570 48.0 32.4 9.8 4.0
2 1045 38.5 25.8 9.5 3.2
MV20D FC/MC62D 24
1 1045 35.8 - - 3.8
2 1570 48.0 32.0 9.8 4.0
2 1045 38.0 25.0 9.5 3.2
HC8B060F1
MV20D FC/MC60D 24
1 1175 43.0 - - 3.4
2 1820 58.0 39.5 9.3 3.8
2 1175 46.5 27.4 9 3.0
MV20D FC/MC62D 24
1 1175 43.0 - - 3.4
2 1820 58.0 39.0 9.3 3.8
2 1175 46.0 27.0 9 3.0
18 SEER HP WITH AV/SV - VARIABLE SPEED
HC8B024F1 AV36 - 21
1 600 19.2 - - 3.8
2 765 24.0 16.9 9.6 4.0
2 600 24.0 15.1 9.3 3.2
HC8B036F1
AV36 - 21
1 830 26.5 - - 4.2
2 1270 36.0 26.6 9.6 4.2
2 830 36.0 24.4 9.3 4.2
AV/SV48 - 24
1 910 27.0 - - 4.6
2 1190 36.0 26.2 10 4.6
2 910 36.0 24.4 9.7 3.6
HC8B048F1
AV/SV48 - 24
1 1135 36.2 - - 4.0
2 1610 48.0 32.4 9.8 4.0
2 1135 38.5 25.6 9.5 3.4
AV/SV60 - 24
1 1085 36.0 - - 4.0
2 1655 48.0 32.6 9.8 4.0
2 1085 39.0 25.8 9.5 3.4
HC8B060F1 AV/SV60 - 24
1 1145 43.0 - - 3.6
2 1765 58.0 39.4 9.3 3.8
2 1145 46.5 27.2 9 3.0
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
