Coleman HC8B024F1 - Page 9

Unitary Products Group 9
345095-CTG-B-0907
HC8B036F1
(F,L)C8(C,V)*C20 FC/MC62D 24
1 780 26.4 - - 4.00
2 1200 36.0 26.2 9.55 4.20
2 780 36.0 23.8 9.35 3.20
FC9(C,V)*C20 FC/MC62D 24
1 790 26.4 - - 4.00
2 1195 36.0 26.0 9.55 4.20
2 790 36.0 24.0 9.35 3.40
FC9(C,V)*D20 FC/MC62D 24
1 775 26.4 - - 4.00
2 1220 36.0 26.0 10 4.40
2 775 36.0 23.8 9.8 3.20
(F,L)C8(C,V)*C16 HC42 21
1 640 26.0 - - 3.80
2 1200 36.0 26.4 9.55 4.20
2 640 36.0 24.4 9.35 3.00
(F,L)C8(C,V)*C20 HC42 21
1 780 26.4 - - 4.00
2 1200 36.0 26.4 9.55 4.00
2 780 36.0 24.4 9.35 3.20
FC9(C,V)*C16 HC42 21
1 770 26.4 - - 4.00
2 1175 36.0 26.4 9.55 4.20
2 770 36.0 24.4 9.35 3.20
FC9(C,V)*C20 HC42 21
1 790 26.4 - - 4.00
2 1195 36.0 26.6 9.55 4.20
2 790 36.0 24.4 9.35 3.20
HC8B048F1
(F,L)C8(C,V)*C16 FC/MC/PC48C 21
1 880 35.5 - - 3.40
2 1500 48.0 33.0 9.3 3.80
2 880 38.0 25.4 9 3.00
(F,L)C8(C,V)*C20 FC/MC/PC48C 21
1 1030 36.0 - - 3.80
2 1610 48.0 32.8 9.3 3.80
2 1030 38.0 25.4 9 3.00
FC9(C,V)*C16 FC/MC/PC48C 21
1 1090 36.0 - - 3.80
2 1600 48.0 33.0 9.3 3.80
2 1090 38.0 25.4 9 3.20
FC9(C,V)*C20 FC/MC/PC48C 21
1 1010 36.0 - - 3.60
2 1580 48.0 33.0 9.3 3.80
2 1010 38.0 25.6 9 3.00
FC9(C,V)*D20 FC/MC/PC48D 24
1 985 36.0 - - 3.60
2 1560 48.0 32.8 9.3 3.80
2 985 38.0 25.6 9 3.00
(F,L)C8(C,V)*C16 FC/PC60C 21
1 880 35.5 - - 3.80
2 1500 48.0 32.8 9.3 3.80
2 880 38.5 25.6 9 3.00
(F,L)C8(C,V)*C20 FC/PC60C 21
1 1030 36.0 - - 4.00
2 1610 48.0 32.8 9.8 4.00
2 1030 39.0 25.6 9.5 3.20
FC9(C,V)*C16 FC/PC60C 21
1 1090 37.0 - - 3.80
2 1600 48.0 33.0 9.8 4.00
2 1090 40.0 26.2 9.5 3.20
FC9(C,V)*C20 FC/PC60C 21
1 1010 36.0 - - 3.80
2 1580 48.0 32.8 9.8 4.00
2 1010 38.5 25.6 9.5 3.20
For Notes, See Page 10.
HEATING CAPACITY - With Variable Speed Furnaces (Continued)
UNIT MODEL
VARIABLE SPEED
FURNACE MODEL
COIL
MODEL
1
W
HEATING
STAGE
RATED
CFM
NET MBH
HSPF
COP @
47
47 OD 17 OD
