3-2 Description and Vehicle Identication
Parking brake lever
Steering wheel
Ignition switch
Light switch
On-Command four-wheel-drive and differential lock
switches
Multi-function display gauge
Auxiliary DC jack
Drive select lever
Accelerator pedal
Brake pedal
Release parking handle
33 Horn
NOTE:
The vehicle you have purchased may differ slightly from
those in the figures of this manual.
25
24
3
