Coleman Revolution User Manual

1
HARDWARE PACK
1/4”-20UNCx38 Screw
X 6
NO.10-24UNCx13 Screw
X 14
1/4”-20UNC Nut
X 2
1/4”-20UNCx16 Screw
X 30
NO.8-32UNCx18 Screw
X 2
ST4.2x10 Tapping Screw
X 6
NO.8-32UNC Nut
X 2
Spacer, Door Handle
X 2
1/4’’-20UNC Screw
X 4
NO.8-32UNCx10 Screw
X 3
Rubberized Washer
X 10
Wheel Lock Pin
X 1
1
2
3
4 5
6
7
8 9
10
11 12
No. Description Part Number Qty.
1 1/4"-20UNCx38 Screw 20120-13038-250 6
2 1/4"-20UNCx16 Screw 20120-13016-250 30
3 1/4''-20UNC Screw G353-0014-9000 4
4 NO.10-24UNCx13 Screw 20124-10013-250 14
5 NO.8-32UNCx18 Screw 20132-08018-250 2
6 NO.8-32UNCx10 Screw 20332-08010-250 3
7 ST4.2x10 Tapping Screw 22500-42010-137B 6
8 Rubberized Washer G501-0054-9100 10
9 1/4"-20UNC Nut 30220-13000-250 2
10 NO.8-32UNC Nut 30232-08000-250 2
11 Spacer, Door Handle G466-0035-9000 2
12 Wheel Lock Pin G350-0026-9000 1
TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (long and short)
• 1/4” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
BEFORE ASSEMBLING THIS BARBECUE, READ THE INSTRUCTIONS CAREFULLY.
Assemble the barbecue on a flat, clean surface. Grill is heavy. Two people are
recommended to assemble this barbecue.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.

Coleman Revolution Specifications

General

Brand	Coleman
Model	Revolution
Category	Grill
Language	English
