Coleman TH4B4223S - Page 10

5523951-CTG-J-0620
10 Johnson Controls Ducted Systems
SYSTEM CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL
CFM RANGE
(MIN.-MAX.)
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
NET MBH
HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
TH4B1821S CF/CM/CU18A 14.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 0.00
TH4B1821S CF/CM/CU18B 17.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.38
TH4B1821S CF/CM/CU24A 14.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.40
TH4B1821S CF/CM/CU24B 17.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.40
TH4B1821S CF/CM24C 21.0 450 - 750 600 17.8 12.6 14.00 12.00 17.5 12.1 8.55 – 3.48 2.36
TH4B1821S CF/CM24C 21.0 450 - 750 600 17.8 12.6 14.00 12.00 17.5 12.1 8.55 – 3.48 2.36
TH4B1821S CF18ABAA1 14.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.38
TH4B1821S CF18BBAA1 17.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.38
TH4B1821S CF24ABAA1 14.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.40
TH4B1821S CF24BBAA1 17.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.40
TH4B1821S CM18ABAA1 14.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.38
TH4B1821S CM24ABAA1 14.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.40
TH4B1821S CM24BBAA1 17.5 450 - 750 600 18.0 13.9 14.00 12.20 18.0 12.1 8.75 7.40 3.52 2.40
TH4B2421S CF/CM/CU24A 14.5 600 - 1000 675 23.6 17.2 14.00 11.50 24.0 15.4 8.20 6.95 3.40 2.30
TH4B2421S CF/CM/CU24B 17.5 600 - 1000 800 24.0 18.7 14.00 11.50 24.0 15.4 8.20 6.95 3.50 2.32
TH4B2421S CF/CM/CU30A 14.5 600 - 1000 675 24.0 18.0 14.75 12.50 24.0 15.6 8.75 7.45 3.62 2.52
TH4B2421S CF/CM/CU30B 17.5 600 - 1000 800 24.0 19.2 14.25 12.20 24.0 15.8 9.00 7.60 3.70 2.50
TH4B2421S CF/CM/CU30D 24.5 600 - 1000 800 24.0 18.3 14.50 12.00 24.0 15.9 8.25 – 3.70 2.50
TH4B2421S CF/CM24C 21.0 600 - 1000 800 23.6 17.2 14.00 11.50 24.0 15.4 8.25 – 3.50 2.32
TH4B2421S CF/CM30C 21.0 600 - 1000 800 24.0 18.3 14.50 12.00 24.0 15.9 8.25 – 3.70 2.50
TH4B2421S CF24ABAA1 14.5 600 - 1000 675 23.6 17.2 14.00 11.50 24.0 15.4 8.20 6.95 3.40 2.30
TH4B2421S CF24BBAA1 17.5 600 - 1000 800 24.0 18.7 14.00 11.50 24.0 15.4 8.20 6.95 3.50 2.32
TH4B2421S CF30ABAA1 14.5 600 - 1000 675 24.0 18.0 14.75 12.50 24.0 15.6 8.75 7.45 3.62 2.52
TH4B2421S CF30BBAA1 17.5 600 - 1000 800 24.0 19.2 14.25 12.20 24.0 15.8 9.00 7.60 3.70 2.50
TH4B2421S CM24ABAA1 14.5 600 - 1000 675 23.6 17.2 14.00 11.50 24.0 15.4 8.20 6.95 3.40 2.30
TH4B2421S CM24BBAA1 17.5 600 - 1000 800 24.0 18.7 14.00 11.50 24.0 15.4 8.20 6.95 3.50 2.32
TH4B2421S CM30BBAA1 17.5 600 - 1000 800 24.0 19.2 14.25 12.20 24.0 15.8 9.00 7.60 3.70 2.50
TH4B3021S CF/CM/CU30B 17.5 800 - 1200 1000 29.0 23.4 14.00 11.75 30.0 20.0 8.55 7.15 3.74 2.62
TH4B3021S CF/CM/CU30C 21.0 800 - 1200 1000 29.0 23.4 14.00 11.75 30.0 20.0 8.55 7.15 3.74 2.62
TH4B3021S CF/CM/CU30D 24.5 800 - 1200 1000 29.0 23.4 14.00 11.75 30.0 20.0 8.55 7.15 3.74 2.62
TH4B3021S CF/CM/CU36B 17.5 800 - 1200 1000 29.6 23.6 14.00 12.00 30.0 20.6 8.55 6.80 4.16 2.80
TH4B3021S CF/CM/CU36C 21.0 800 - 1200 1000 29.6 23.6 14.00 12.00 30.0 20.6 8.55 6.80 4.16 2.80
TH4B3021S CF/CM/CU36D 24.5 800 - 1200 1000 29.6 23.6 14.00 12.00 30.0 20.6 8.55 6.80 4.16 2.80
TH4B3021S CF/CM/CU42C 21.0 800 - 1200 1000 29.2 21.8 14.00 12.00 29.2 19.6 8.50 – 3.74 2.60
TH4B3021S CF/CM30C 21.0 800 - 1200 1000 29.0 23.4 14.00 11.75 30.0 20.0 8.55 7.15 3.74 2.62
TH4B3021S CF/CM36A 14.5 800 - 1200 1000 29.6 23.6 14.00 12.00 30.0 20.6 8.55 6.80 4.16 2.80
TH4B3021S CF/CM36D 24.5 800 - 1200 1000 29.6 23.6 14.00 12.00 30.0 20.6 8.55 6.80 4.16 2.80
