5523951-CTG-J-0620
Johnson Controls Ducted Systems 11
— = Not Applicable.
MP Modular Air Handlers use Coil Only Ratings.
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
TH4B3021S CF/CM42D 24.5 800 - 1200 1000 29.2 21.8 14.00 12.00 29.2 19.6 8.50 – 3.74 2.60
TH4B3021S CF30BBBA1 17.5 800 - 1200 1000 29.0 23.4 14.00 11.75 30.0 20.0 8.55 7.15 3.74 2.62
TH4B3021S CM30BBBA1 17.5 800 - 1200 1000 29.0 23.4 14.00 11.75 30.0 20.0 8.55 7.15 3.74 2.62
TH4B3622S CF/CM/CU48C 21.0 1000 - 1400 1200 36.0 28.7 14.25 12.20 35.8 23.4 8.50 7.75 3.54 2.46
TH4B3622S CF/CM/CU48D 24.5 1000 - 1400 1200 36.0 28.7 14.25 12.20 35.8 23.4 8.50 7.75 3.54 2.46
TH4B4223S CF/CM/CU48C 21.0 1200 - 1600 1400 40.5 31.9 14.00 11.25 40.5 26.0 8.20 7.30 3.32 2.54
TH4B4223S CF/CM/CU48D 24.5 1200 - 1600 1400 40.5 31.9 14.00 11.25 40.5 26.0 8.20 7.30 3.32 2.54
TH4B4223S CF48CBCA1 21.0 1200 - 1600 1400 40.5 31.9 14.00 11.25 40.5 26.0 8.20 7.30 3.32 2.54
TH4B4223S CM48CBCA1 21.0 1200 - 1600 1400 40.5 31.9 14.00 11.25 40.5 26.0 8.20 7.30 3.32 2.54
TH4B4223S CM48DBCA1 24.5 1200 - 1600 1400 40.5 31.9 14.00 11.25 40.5 26.0 8.20 7.30 3.32 2.54
TH4B4822S CF/CM/CU60C 21.0 1400 - 1800 1600 47.0 33.0 14.00 12.00 47.5 35.2 8.20 – 4.04 2.96
TH4B4822S CF/CM/CU60D 24.5 1400 - 1800 1600 47.0 33.0 14.00 12.00 47.5 35.2 8.20 – 4.04 2.96
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
SYSTEM CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL
CFM RANGE
(MIN.-MAX.)
COOLING HEATING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
NET MBH
HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
