Coleman TH4B4223S - Page 7

5523951-CTG-J-0620
Johnson Controls Ducted Systems 7
TH4B3021S ME12CN21 21.0 CF/CM30C 825 29.0 21.4 15.75 13.00 30.0 19.4 9.50 8.00 3.88 2.74
TH4B3021S ME14DN21 24.5 CF/CM30D 825 29.0 21.4 15.75 13.00 30.0 19.4 9.50 8.00 3.88 2.74
TH4B3021S ME14DN21 24.5 CF/CM36D 825 29.8 21.8 15.75 13.00 30.0 19.8 9.50 7.60 4.34 2.96
TH4B3021S ME16CN21 21.0 CF/CM30C 900 29.4 22.6 15.75 13.00 29.8 19.4 9.50 7.95 3.96 2.74
TH4B3021S ME16CN21 21.0 CF/CM36C 900 30.0 22.8 15.75 13.00 30.0 19.8 9.50 7.55 4.40 2.96
TH4B3021S MVC12BN21 17.5 CF/CM30B 875 29.2 22.2 15.75 13.00 30.0 19.4 9.50 7.95 3.92 2.76
TH4B3021S MVC12BN21 17.5 CF/CM36B 875 29.8 22.4 15.75 13.00 30.0 19.9 9.50 7.60 4.36 2.94
TH4B3021S MVC12CN21 21.0 CF/CM30C 875 29.2 22.2 15.75 13.00 29.8 19.3 9.50 7.95 3.96 2.78
TH4B3021S MVC12CN21 21.0 CF/CM36C 875 30.0 22.6 15.75 13.00 30.0 19.8 9.50 7.55 4.40 2.98
TH4B3021S MVC14DN21 24.5 CF/CM30D 875 29.4 22.4 15.75 13.00 29.8 19.3 9.50 7.95 3.98 2.78
TH4B3021S MVC14DN21 24.5 CF/CM36D 875 30.0 22.6 15.75 13.00 30.0 19.7 9.50 7.55 4.42 2.98
TH4B3021S MVC16CN21 21.0 CF/CM30C 925 29.6 23.0 15.75 13.00 29.8 19.3 9.50 7.90 4.02 2.78
TH4B3021S MVC16CN21 21.0 CF/CM36C 925 30.0 23.2 15.75 13.00 30.0 19.8 9.50 7.55 4.46 3.00
TH4B3521S AE36BX21 17.5 – 1000 34.6 25.4 14.00 12.25 34.0 22.0 8.20 7.35 3.48 2.30
TH4B3521S AE36CX21 21.0 – 1225 35.2 26.2 14.50 12.00 34.0 21.6 8.90 7.70 3.64 2.48
TH4B3521S AVC36BX21 17.5 – 1000 34.4 25.2 14.00 12.20 34.0 22.2 8.20 7.35 3.46 2.30
TH4B3521S AVC36CX21 21.0 – 1025 34.8 25.8 14.25 12.25 33.8 22.0 8.55 7.40 3.52 2.32
TH4B3521S ME12BN21 17.5 CF/CM36B 1050 34.6 26.0 14.25 12.20 34.0 21.8 8.55 7.40 3.52 2.44
TH4B3521S ME12BN21 17.5 CF42B 1050 35.0 26.2 14.50 12.20 33.6 21.6 8.55 7.40 3.60 2.44
TH4B3521S ME12CN21 21.0 CF/CM36C 1000 34.6 25.4 14.25 12.25 33.8 22.0 8.20 7.40 3.50 2.32
TH4B3521S ME14DN21 24.5 CF/CM36D 825 33.6 23.0 14.75 12.20 33.6 21.8 8.20 7.30 3.36 2.30
TH4B3521S ME16CN21 21.0 CF/CM36C 1100 34.8 26.8 14.50 12.25 33.8 21.6 8.55 7.40 3.58 2.46
TH4B3521S ME16CN21 21.0 CF/CM42C 1100 35.6 27.0 14.75 12.25 33.6 21.4 8.55 7.35 3.64 2.46
TH4B3521S MVC12BN21 17.5 CF/CM36B 1025 34.6 25.8 14.00 12.25 34.0 22.2 8.20 7.35 3.50 2.30
TH4B3521S MVC12BN21 17.5 CF42B 1025 35.0 26.0 14.50 12.20 33.6 21.6 8.55 7.40 3.58 2.44
TH4B3521S MVC12CN21 21.0 CF/CM36C 1000 34.8 25.6 14.25 12.50 33.8 22.0 8.55 7.40 3.52 2.32
TH4B3521S MVC12CN21 21.0 CF/CM42C 1000 35.0 25.6 15.00 12.25 33.4 21.4 8.55 7.40 3.60 2.46
TH4B3521S MVC14DN21 24.5 CF/CM36D 875 34.0 24.0 14.50 12.25 33.6 21.6 8.20 7.45 3.44 2.36
TH4B3521S MVC16CN21 21.0 CF/CM36C 1025 34.8 25.8 14.50 12.50 33.8 22.0 8.55 7.40 3.54 2.32
TH4B3521S MVC16CN21 21.0 CF/CM42C 1025 35.2 26.0 15.00 12.25 33.4 21.4 8.55 7.40 3.62 2.46
TH4B3622S AE42CBF21 21.0 – 1000 36.0 25.8 15.75 13.00 34.8 22.4 8.75 – 3.64 2.58
TH4B3622S AE42CX21 21.0 – 1000 36.0 25.8 15.75 13.00 34.8 22.4 8.75 – 3.64 2.58
TH4B3622S AE48CX21 21.0 – 1050 36.0 27.3 15.75 12.75 34.8 22.4 9.00 7.70 3.70 2.60
TH4B3622S AE48DX21 24.5 – 1050 36.0 27.5 16.00 13.00 34.8 22.4 9.00 7.65 3.76 2.62
TH4B3622S AP37CBA21 21.0 – 1200 36.0 25.2 14.00 12.00 35.8 23.4 8.75 7.75 3.54 2.46
TH4B3622S AP37CBF21 21.0 – 1200 36.0 25.2 14.00 12.00 35.8 23.4 8.75 7.75 3.54 2.46
TH4B3622S AP37CX21 21.0 – 1200 36.0 25.2 14.00 12.00 35.8 23.4 8.75 7.75 3.54 2.46
TH4B3622S AP48DX21 24.5 – 1350 36.0 30.6 14.00 11.75 36.0 23.6 8.50 7.75 3.56 2.46
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
RATED
CFM
COOLING
1
HEATING
2
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
