Coleman TH4B4223S - Page 8

5523951-CTG-J-0620
8 Johnson Controls Ducted Systems
TH4B3622S AVC42CX21 21.0 – 1150 36.2 27.2 15.75 13.00 35.0 22.6 9.00 8.00 3.70 2.58
TH4B3622S AVC48CX21 21.0 – 1025 36.0 26.9 15.75 12.75 34.8 22.6 8.75 7.50 3.64 2.58
TH4B3622S AVC48DX21 24.5 – 1025 36.0 27.1 16.00 13.00 34.8 22.4 9.00 7.70 3.66 2.58
TH4B3622S ME12CN21 21.0 CF/CM48C 1000 36.0 26.7 15.75 12.75 34.8 22.6 8.75 7.50 3.62 2.58
TH4B3622S ME14DN21 24.5 CF/CM48D 1025 36.0 27.1 16.00 13.00 34.8 22.4 9.00 7.70 3.66 2.58
TH4B3622S ME16CN21 21.0 CF/CM48C 1100 36.0 28.0 15.75 12.75 35.0 22.6 9.00 7.70 3.70 2.58
TH4B3622S ME20DN21 24.5 CF/CM48D 1275 36.0 30.3 16.00 13.00 34.8 22.4 9.25 7.85 3.82 2.64
TH4B3622S MVC12CN21 21.0 CF/CM48C 1000 36.0 26.7 15.75 12.75 34.8 22.4 8.75 7.50 3.64 2.58
TH4B3622S MVC14DN21 24.5 CF/CM48D 1000 36.0 26.7 16.00 13.00 34.8 22.4 9.00 7.75 3.66 2.60
TH4B3622S MVC16CN21 21.0 CF/CM48C 1025 36.0 27.1 15.75 12.75 34.8 22.4 9.00 7.70 3.66 2.58
TH4B3622S MVC20DN21 24.5 CF/CM48D 1175 36.0 29.4 16.00 13.00 34.8 22.4 9.00 7.65 3.78 2.62
TH4B4223S AE42CX21 21.0 – 1150 40.0 29.1 15.00 12.25 40.0 25.2 8.20 7.25 3.36 2.64
TH4B4223S AE48CBC21 21.0 – 1200 40.5 30.0 15.25 12.25 40.0 25.2 8.20 7.25 3.44 2.66
TH4B4223S AE48CX21 21.0 – 1200 40.5 30.0 15.25 12.25 40.0 25.2 8.20 7.25 3.44 2.66
TH4B4223S AE48DBC21 24.5 – 1250 40.5 30.6 15.50 12.50 39.5 250. 8.50 7.50 3.50 2.70
TH4B4223S AE48DX21 24.5 – 1250 40.5 30.6 15.50 12.50 39.5 25.0 8.50 7.50 3.50 2.70
TH4B4223S AP48CBC21 21.0 – 1450 41.0 30.2 14.00 11.75 40.5 25.8 8.20 7.55 3.34 2.58
TH4B4223S AP48CX21 21.0 – 1450 41.0 30.2 14.00 11.75 40.5 25.8 8.20 7.55 3.34 2.58
TH4B4223S AP48DX21 24.5 – 1475 41.0 33.3 14.00 11.25 40.5 26.0 8.20 7.25 3.36 2.56
TH4B4223S AVC42CX21 21.0 – 1150 40.0 29.1 15.00 12.25 40.0 25.4 8.20 7.25 3.34 2.62
TH4B4223S AVC48CX21 21.0 – 1200 40.5 30.1 15.00 12.25 40.0 25.4 8.20 7.25 3.38 2.64
TH4B4223S AVC48DX21 24.5 – 1150 40.5 29.6 15.50 12.25 40.0 25.2 8.20 7.25 3.38 2.66
TH4B4223S ME14DN21 24.5 CF/CM48D 1200 40.5 30.0 15.25 12.25 40.0 25.2 8.20 7.25 3.40 2.66
TH4B4223S ME14DN21 24.5 CM48DBCA1 1200 40.5 30.0 15.25 12.25 40.0 25.2 8.20 7.25 3.40 2.66
TH4B4223S ME16CN21 21.0 CF/CM48C 1325 40.5 31.4 15.00 12.20 40.0 25.4 8.20 7.25 3.42 2.64
TH4B4223S ME16CN21 21.0 CF48CBCA1 1325 40.5 31.4 15.00 12.20 40.0 25.4 8.20 7.25 3.42 2.64
TH4B4223S ME16CN21 21.0 CM48CBCA1 1325 40.5 31.4 15.00 12.20 40.0 25.4 8.20 7.25 3.42 2.64
TH4B4223S ME20DN21 24.5 CF/CM48D 1275 41.0 31.2 15.50 12.50 39.5 25.2 8.50 7.50 3.46 2.66
TH4B4223S ME20DN21 24.5 CM48DBCA1 1275 41.0 31.2 15.50 12.50 39.5 25.2 8.50 7.50 3.46 2.66
TH4B4223S MVC14DN21 24.5 CF/CM48D 1175 40.5 29.8 15.50 12.50 40.0 25.0 8.20 7.25 3.40 2.68
TH4B4223S MVC14DN21 24.5 CM48DBCA1 1175 40.5 29.8 15.50 12.50 40.0 25.0 8.20 7.25 3.40 2.68
TH4B4223S MVC16CN21 21.0 CF/CM48C 1150 40.5 29.6 15.25 12.25 40.0 25.2 8.20 7.25 3.36 2.66
TH4B4223S MVC16CN21 21.0 CF48CBCA1 1150 40.5 29.6 15.25 12.25 40.0 25.2 8.20 7.25 3.36 2.66
TH4B4223S MVC16CN21 21.0 CM48CBCA1 1150 40.5 29.6 15.25 12.25 40.0 25.2 8.20 7.25 3.36 2.66
TH4B4223S MVC20DN21 24.5 CF/CM48D 1175 40.5 29.8 15.50 12.50 40.0 25.0 8.20 7.25 3.40 2.68
TH4B4223S MVC20DN21 24.5 CM48DBCA1 1175 40.5 29.8 15.50 12.50 40.0 25.0 8.20 7.25 3.40 2.68
TH4B4223S AE48CBC21 21.0 – 1400 46.0 31.8 14.25 12.00 47.5 31.4 9.00 – 3.58 2.64
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
RATED
CFM
COOLING
1
HEATING
2
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
