Coleman TH4B6021S - Page 10

5005749-CTG-A-0216
10 Johnson Controls Unitary Products
TH4B1821S TP9C080B12MP12 17.5 CF/CM/CU24B 575 18.0 12.7 15.00 12.75 17.5 11.7 8.75 3.80 2.56 16.3 14.5
TH4B1821S TPLC060A12MP12 14.5 CF/CM/CU18A 525 17.6 12.0 14.25 12.25 17.3 11.8 8.50 3.56 2.46 16.4 14.5
TH4B1821S TPLC080B12MP12 17.5 CF/CM/CU24B 675 18.0 13.5 14.75 12.50 17.5 11.8 8.50 3.82 2.54 16.1 14.3
TH4B1821S CP9C060B12MP12 17.5 CF/CM/CU24B 575 18.0 12.7 15.00 12.75 17.5 11.7 8.75 3.80 2.56 16.3 14.5
TH4B1821S CP9C080B12MP12 17.5 CF/CM/CU24B 575 18.0 12.7 15.00 12.75 17.5 11.7 8.75 3.80 2.56 16.3 14.5
TH4B1821S CPLC060A12MP12 14.5 CF/CM/CU18A 525 17.6 12.0 14.25 12.25 17.3 11.8 8.50 3.56 2.46 16.4 14.5
TH4B1821S CPLC080B12MP12 17.5 CF/CM/CU24B 675 18.0 13.5 14.75 12.50 17.5 11.8 8.50 3.82 2.54 16.1 14.3
TH4B2421S TM8V060A12MP11 14.5 CF/CM/CU24A 725 23.6 16.4 14.75 12.25 23.4 15.1 8.25 3.54 2.40 22.1 19.8
TH4B2421S TM8V060A12MP11 14.5 CF/CM/CU30A 725 24.0 16.9 15.75 12.75 23.8 15.5 8.50 3.78 2.58 22.1 20.0
TH4B2421S TM8V080B12MP11 17.5 CF/CM/CU24B 675 23.6 15.9 15.00 12.50 23.2 15.0 8.25 3.52 2.40 22.3 19.9
TH4B2421S TM8V080B12MP11 17.5 CF/CM/CU30B 800 24.0 17.4 15.75 13.00 24.0 15.5 8.50 3.88 2.60 21.8 19.7
TH4B2421S TM8X060A12MP11 14.5 CF/CM/CU24A 800 24.0 17.1 15.25 12.75 23.6 15.0 8.50 3.70 2.44 21.8 19.3
TH4B2421S TM8X060A12MP11 14.5 CF/CM/CU30A 700 24.0 16.6 16.00 13.00 23.6 15.3 8.50 3.82 2.62 22.2 20.1
TH4B2421S TM8X080B12MP11 17.5 CF/CM/CU24B 725 23.6 16.5 15.50 12.75 23.2 14.9 8.50 3.62 2.46 22.1 19.9
TH4B2421S TM8X080B12MP11 17.5 CF/CM/CU30B 725 24.0 16.9 16.00 13.00 23.6 15.3 8.50 3.88 2.64 22.1 20.1
TH4B2421S TM8X080C16MP11 21.0 CF/CM/CU24C 800 24.0 17.2 15.75 13.00 23.4 14.9 8.50 3.74 2.46 21.8 19.4
TH4B2421S TM8X080C16MP11 21.0 CF/CM/CU30C 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.6
TH4B2421S TM8X080C16MP11 21.0 CF/CM/CU30D 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.6
TH4B2421S TM8X100C16MP11 21.0 CF/CM/CU24C 800 24.0 17.2 15.75 13.00 23.4 14.9 8.50 3.74 2.46 21.8 19.5
TH4B2421S TM8X100C16MP11 21.0 CF/CM/CU30C 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.5
TH4B2421S TM8X100C16MP11 21.0 CF/CM/CU30D 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.5
TH4B2421S TM8X100C20MP11 21.0 CF/CM/CU30C 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TM8X100C20MP11 21.0 CF/CM/CU30D 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TM8X120C20MP11 21.0 CF/CM/CU30C 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TM8X120C20MP11 21.0 CF/CM/CU30D 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TM8Y060A12MP11 14.5 CF/CM/CU24A 800 24.0 17.1 15.25 12.75 23.6 15.0 8.50 3.70 2.44 21.8 19.3
TH4B2421S TM8Y060A12MP11 14.5 CF/CM/CU30A 700 24.0 16.6 16.00 13.00 23.6 15.3 8.50 3.82 2.62 22.2 20.1
TH4B2421S TM8Y080B12MP11 17.5 CF/CM/CU24B 725 23.6 16.5 15.50 12.75 23.2 14.9 8.50 3.62 2.46 22.1 19.9
TH4B2421S TM8Y080B12MP11 17.5 CF/CM/CU30B 725 24.0 16.9 16.00 13.00 23.6 15.3 8.50 3.88 2.64 22.1 20.1
TH4B2421S TM8Y080C16MP11 21.0 CF/CM/CU24C 800 24.0 17.2 15.75 13.00 23.4 14.9 8.50 3.74 2.46 21.8 19.4
TH4B2421S TM8Y080C16MP11 21.0 CF/CM/CU30C 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.6
TH4B2421S TM8Y080C16MP11 21.0 CF/CM/CU30D 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.6
TH4B2421S TM8Y100C16MP11 21.0 CF/CM/CU24C 800 24.0 17.2 15.75 13.00 23.4 14.9 8.50 3.74 2.46 21.8 19.5
TH4B2421S TM8Y100C16MP11 21.0 CF/CM/CU30C 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.5
TH4B2421S TM8Y100C16MP11 21.0 CF/CM/CU30D 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.5
TH4B2421S TM8Y100C20MP11 21.0 CF/CM/CU30C 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TM8Y100C20MP11 21.0 CF/CM/CU30D 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
