Coleman TH4B6021S - SYSTEM CAPACITY - with High Efficiency Motor Furnaces

5005749-CTG-A-0216
Johnson Controls Unitary Products 9
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
TH4B1821S TM8V060A12MP11 14.5 CF/CM/CU18A 525 17.6 12.0 14.25 12.25 17.3 11.8 8.50 3.56 2.46 16.4 14.5
TH4B1821S TM8V080B12MP11 17.5 CF/CM/CU24B 675 18.0 13.5 14.75 12.50 17.5 11.8 8.50 3.82 2.54 16.1 14.3
TH4B1821S TM8X060A12MP11 14.5 CF/CM/CU18A 600 17.9 12.8 14.25 12.25 17.5 11.9 8.50 3.64 2.46 16.2 14.4
TH4B1821S TM8X060A12MP11 14.5 CF/CM/CU24A 600 17.9 12.7 14.50 12.25 17.5 11.8 8.50 3.70 2.50 16.2 14.3
TH4B1821S TM8X080B12MP11 17.5 CF/CM/CU18B 600 17.9 12.8 14.50 12.25 17.5 11.9 8.50 3.66 2.48 16.2 14.4
TH4B1821S TM8X080B12MP11 17.5 CF/CM/CU24B 600 18.0 12.7 14.50 12.25 17.5 11.8 8.50 3.70 2.50 16.2 14.2
TH4B1821S TM8X080C16MP11 21.0 CF/CM/CU24C 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.68 2.48 16.2 14.3
TH4B1821S TM8X100C16MP11 21.0 CF/CM/CU24C 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.68 2.48 16.2 14.3
TH4B1821S TM8Y060A12MP11 14.5 CF/CM/CU18A 600 17.9 12.8 14.25 12.25 17.5 11.9 8.50 3.64 2.46 16.2 14.4
TH4B1821S TM8Y060A12MP11 14.5 CF/CM/CU24A 600 17.9 12.7 14.50 12.25 17.5 11.8 8.50 3.70 2.50 16.2 14.3
TH4B1821S TM8Y080B12MP11 17.5 CF/CM/CU18B 600 17.9 12.8 14.50 12.25 17.5 11.9 8.50 3.66 2.48 16.2 14.4
TH4B1821S TM8Y080B12MP11 17.5 CF/CM/CU24B 600 18.0 12.7 14.50 12.25 17.5 11.8 8.50 3.70 2.50 16.2 14.2
TH4B1821S TM8Y080C16MP11 21.0 CF/CM/CU24C 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.68 2.48 16.2 14.3
TH4B1821S TM8Y100C16MP11 21.0 CF/CM/CU24C 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.68 2.48 16.2 14.3
TH4B1821S TM9E040A10MP11 14.5 CF/CM/CU18A 600 17.9 12.8 14.50 12.50 17.5 11.9 8.50 3.68 2.48 16.2 14.4
TH4B1821S TM9E040A10MP11 14.5 CF/CM/CU24A 575 18.0 12.8 14.50 12.50 17.5 11.8 8.50 3.72 2.52 16.3 14.6
TH4B1821S TM9E060B12MP11 17.5 CF/CM/CU24B 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.66 2.48 16.2 14.3
TH4B1821S TM9E080B12MP11 17.5 CF/CM/CU24B 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.66 2.48 16.2 14.3
TH4B1821S TM9E080C16MP11 21.0 CF/CM/CU24C 600 18.0 12.8 14.75 12.50 17.5 11.8 8.75 3.76 2.54 16.2 14.3
TH4B1821S TM9E100C16MP11 21.0 CF/CM/CU24C 600 18.0 12.8 14.75 12.50 17.5 11.8 8.75 3.76 2.54 16.2 14.3
TH4B1821S TM9V060B12MP11 17.5 CF/CM/CU24B 575 18.0 12.7 15.00 12.75 17.5 11.7 8.75 3.80 2.56 16.3 14.5
TH4B1821S TM9V080B12MP11 17.5 CF/CM/CU24B 575 18.0 12.7 15.00 12.75 17.5 11.7 8.75 3.80 2.56 16.3 14.5
TH4B1821S TM9Y040A10MP11 14.5 CF/CM/CU18A 600 17.9 12.8 14.50 12.50 17.5 11.9 8.50 3.68 2.48 16.2 14.4
TH4B1821S TM9Y040A10MP11 14.5 CF/CM/CU24A 575 18.0 12.8 14.50 12.50 17.5 11.8 8.50 3.72 2.52 16.3 14.6
TH4B1821S TM9Y060B12MP11 17.5 CF/CM/CU24B 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.66 2.48 16.2 14.3
TH4B1821S TM9Y080B12MP11 17.5 CF/CM/CU24B 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.66 2.48 16.2 14.3
TH4B1821S TM9Y080C16MP11 21.0 CF/CM/CU24C 600 18.0 12.8 14.75 12.50 17.5 11.8 8.75 3.76 2.54 16.2 14.3
TH4B1821S TM9Y100C16MP11 21.0 CF/CM/CU24C 600 18.0 12.8 14.75 12.50 17.5 11.8 8.75 3.76 2.54 16.2 14.3
TH4B1821S TMLV060A12MP11 14.5 CF/CM/CU18A 525 17.6 12.0 14.25 12.25 17.3 11.8 8.50 3.56 2.46 16.4 14.5
TH4B1821S TMLV080B12MP11 17.5 CF/CM/CU24B 675 18.0 13.5 14.75 12.50 17.5 11.8 8.50 3.82 2.54 16.1 14.3
TH4B1821S TMLX060A12MP11 14.5 CF/CM/CU18A 600 17.9 12.8 14.25 12.25 17.5 11.9 8.50 3.64 2.46 16.2 14.4
TH4B1821S TMLX060A12MP11 14.5 CF/CM/CU24A 600 17.9 12.7 14.50 12.25 17.5 11.8 8.50 3.70 2.50 16.2 14.3
TH4B1821S TMLX080B12MP11 17.5 CF/CM/CU18B 600 17.9 12.8 14.50 12.25 17.5 11.9 8.50 3.66 2.48 16.2 14.4
TH4B1821S TMLX080B12MP11 17.5 CF/CM/CU24B 600 18.0 12.7 14.50 12.25 17.5 11.8 8.50 3.70 2.50 16.2 14.2
TH4B1821S TMLX080C16MP11 21.0 CF/CM/CU24C 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.68 2.48 16.2 14.3
TH4B1821S TMLX100C16MP11 21.0 CF/CM/CU24C 600 17.9 12.7 14.25 12.25 17.5 11.9 8.50 3.68 2.48 16.2 14.3
TH4B1821S TP9C060B12MP12 17.5 CF/CM/CU24B 575 18.0 12.7 15.00 12.75 17.5 11.7 8.75 3.80 2.56 16.3 14.5
For Notes See Page 29.
