Coleman TH4B6021S - Page 28

5005749-CTG-A-0216
28 Johnson Controls Unitary Products
TH4B4821S TMLX100C16MP11 21.0 CF/CM/CU48C 1400 46.0 31.6 14.00 11.75 48.0 31.6 9.00 3.54 2.6 41.5 33.4
TH4B4821S TMLX100C16MP11 21.0 CF/CM/CU48D 1400 46.0 31.6 14.00 11.75 48.0 31.6 9.00 3.54 2.6 41.5 33.4
TH4B4821S TMLX100C16MP11 21.0 CF/CM/CU60C 1400 46.5 32.0 14.25 12.00 48.0 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TMLX100C16MP11 21.0 CF/CM/CU60D 1400 46.5 32.0 14.25 12.00 48.0 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TMLX120C20MP11 21.0 CF/CM/CU48C 1400 46.0 31.8 14.00 11.75 48.0 31.6 9.00 3.56 2.6 41.5 33.4
TH4B4821S TMLX120C20MP11 21.0 CF/CM/CU48D 1400 46.0 31.8 14.00 11.75 48.0 31.6 9.00 3.56 2.6 41.5 33.4
TH4B4821S TMLX120C20MP11 21.0 CF/CM/CU60C 1400 46.5 32.0 14.25 12.00 47.5 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TMLX120C20MP11 21.0 CF/CM/CU60D 1400 46.5 32.0 14.25 12.00 47.5 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TM8Y100C16MP11 21.0 CF/CM/CU48C 1400 46.0 31.6 14.00 11.75 48.0 31.6 9.00 3.54 2.6 41.5 33.4
TH4B4821S TM8Y100C16MP11 21.0 CF/CM/CU48D 1400 46.0 31.6 14.00 11.75 48.0 31.6 9.00 3.54 2.6 41.5 33.4
TH4B4821S TM8Y100C16MP11 21.0 CF/CM/CU60C 1400 46.5 32.0 14.25 12.00 48.0 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TM8Y100C16MP11 21.0 CF/CM/CU60D 1400 46.5 32.0 14.25 12.00 48.0 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TM8Y120C20MP11 21.0 CF/CM/CU48C 1400 46.0 31.8 14.00 11.75 48.0 31.6 9.00 3.56 2.6 41.5 33.4
TH4B4821S TM8Y120C20MP11 21.0 CF/CM/CU48D 1400 46.0 31.8 14.00 11.75 48.0 31.6 9.00 3.56 2.6 41.5 33.4
TH4B4821S TM8Y120C20MP11 21.0 CF/CM/CU60C 1400 46.5 32.0 14.25 12.00 47.5 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TM8Y120C20MP11 21.0 CF/CM/CU60D 1400 46.5 32.0 14.25 12.00 47.5 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TM9Y100C16MP11 21.0 CF/CM/CU48C 1325 45.5 30.8 14.00 11.75 47.5 31.6 9.00 3.48 2.6 41.1 33.4
TH4B4821S TM9Y100C16MP11 21.0 CF/CM/CU60C 1325 46.0 31.0 14.25 11.75 47.5 31.4 9.00 3.48 2.6 41.5 33.4
TH4B4821S TM9Y100C16MP11 21.0 CF/CM/CU60D 1325 46.0 31.0 14.25 11.75 47.5 31.4 9.00 3.48 2.6 41.5 33.4
TH4B4821S TM9Y100C20MP11 21.0 CF/CM/CU48C 1400 46.0 31.8 14.00 11.75 48.0 31.6 9.00 3.54 2.6 41.5 33.4
TH4B4821S TM9Y100C20MP11 21.0 CF/CM/CU48D 1400 46.0 31.6 14.00 11.75 48.0 31.6 9.00 3.54 2.6 41.5 33.4
TH4B4821S TM9Y100C20MP11 21.0 CF/CM/CU60C 1400 46.5 32.0 14.25 12.00 47.5 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TM9Y100C20MP11 21.0 CF/CM/CU60D 1400 46.5 32.0 14.25 12.00 47.5 31.4 9.00 3.54 2.6 42.0 33.7
TH4B4821S TM9Y120D20MP11 24.5 CF/CM/CU48D 1400 46.0 31.8 14.25 11.75 48.0 31.6 9.00 3.56 2.6 41.5 33.4
TH4B4821S TM9Y120D20MP11 24.5 CF/CM/CU60D 1400 47.0 32.2 14.50 12.00 47.5 31.4 9.00 3.56 2.6 42.4 34.1
TH4B4821S CP9C100C16MP11 21.0 CF/CM/CU48C 1425 46.0 31.6 14.00 11.75 48.0 31.8 9.00 3.52 2.6 41.5 33.1
TH4B4821S CP9C100C16MP11 21.0 CF/CM/CU48D 1425 46.0 31.8 14.25 12.00 47.5 31.4 9.00 3.58 2.6 41.5 33.4
TH4B4821S CP9C100C16MP11 21.0 CF/CM/CU60C 1450 46.5 32.0 14.00 11.75 48.0 31.6 8.75 3.50 2.6 42.0 33.1
TH4B4821S CP9C100C20MP11 21.0 CF/CM/CU48C 1275 45.5 30.2 14.00 11.75 47.5 31.4 9.00 3.46 2.6 41.1 33.1
TH4B4821S CP9C100C20MP11 21.0 CF/CM/CU48D 1300 45.5 30.6 14.25 11.75 47.5 31.4 9.00 3.50 2.6 41.1 33.4
TH4B4821S CP9C100C20MP11 21.0 CF/CM/CU60C 1450 46.5 31.8 14.00 11.75 48.0 31.6 8.75 3.50 2.6 42.0 33.1
TH4B4821S CP9C120D20MP11 24.5 CF/CM/CU60D 1425 46.5 32.2 14.25 12.00 47.5 31.4 9.00 3.56 2.6 42.0 33.7
TH4B4821S TP9C100C16MP11 21.0 CF/CM/CU48C 1425 46.0 31.6 14.00 11.75 48.0 31.8 9.00 3.52 2.6 41.5 33.1
TH4B4821S TP9C100C16MP11 21.0 CF/CM/CU48D 1425 46.0 31.8 14.25 12.00 47.5 31.4 9.00 3.58 2.6 41.5 33.4
TH4B4821S TP9C100C16MP11 21.0 CF/CM/CU60C 1450 46.5 32.0 14.00 11.75 48.0 31.6 8.75 3.50 2.6 42.0 33.1
TH4B4821S TP9C100C20MP11 21.0 CF/CM/CU48C 1275 45.5 30.2 14.00 11.75 47.5 31.4 9.00 3.46 2.6 41.1 33.1
TH4B4821S TP9C100C20MP11 21.0 CF/CM/CU48D 1300 45.5 30.6 14.25 11.75 47.5 31.4 9.00 3.50 2.6 41.1 33.4
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
