Coleman TH4B6021S - Page 39

5005749-CTG-A-0216
Johnson Controls Unitary Products 39
COIL MULTIPLIERS - 2 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU24A 1.00 1.01 1.02
– CF/CM/CU24B 1.00 1.01 1.02
– CF/CM/CU24C 1.00 1.01 1.02
– CF/CM/CU30B 1.00 1.02 0.98
– CF/CM/CU30C 1.00 1.02 0.98
– CF/CM/CU30D 1.00 1.02 0.98
AE24BX21 – 1.00 1.02 0.90
AE30BX21 – 1.00 1.03 0.90
AP24BX21 – 1.00 1.00 0.99
AP30BX21 – 1.00 1.02 0.94
AVC24BX21 – 1.01 1.02 0.93
AVC30BX21 – 1.01 1.03 0.91
ME08BN21 CF/CM24B 1.00 1.01 0.90
ME08BN21 CF/CM30B 1.00 1.02 0.90
ME12BN21 CF/CM24B 1.00 1.01 0.92
ME12BN21 CF/CM30B 1.00 1.02 0.90
ME14DN21 CF/CM30D 1.00 1.03 0.90
ME16CN21 CF/CM24C 0.99 1.00 0.97
MVC08BN21 CF/CM24B 1.00 1.01 0.90
MVC08BN21 CF/CM30B 1.02 1.05 0.92
MVC12BN21 CF/CM24B 1.00 1.00 0.92
MVC12BN21 CF/CM30B 1.02 1.05 0.92
MVC14DN21 CF/CM30D 1.00 1.02 0.90
FURNACE MULTIPLIERS - 2 TON
Furnaces Coil T.C. S.C. KW
TM8V060A12MP11 CF/CM/CU24A 0.99 0.96 0.95
TM8V060A12MP11 CF/CM/CU30A 1.01 0.99 0.93
TM8V080B12MP11 CF/CM/CU24B 0.99 0.93 0.93
TM8V080B12MP11 CF/CM/CU30B 1.01 1.02 0.91
TM8X060A12MP11 CF/CM/CU24A 1.01 1.00 0.93
TM8X060A12MP11 CF/CM/CU30A 1.01 0.97 0.91
TM8X080B12MP11 CF/CM/CU24B 0.99 0.97 0.91
TM8X080B12MP11 CF/CM/CU30B 1.01 0.99 0.91
TM8X080C16MP11 CF/CM/CU30C 1.01 1.02 0.91
TM8V060A12MP11 CF/CM/CU24A 1.02 1.03 0.97
TM8V060A12MP11 CF/CM/CU30A 1.02 1.04 0.92
TM8V080B12MP11 CF/CM/CU24B 1.03 1.04 0.96
TM8V080B12MP11 CF/CM/CU30B 1.00 1.03 0.90
TM8X060A12MP11 CF/CM/CU24A 1.00 1.00 0.92
TM8X060A12MP11 CF/CM/CU30A 1.02 1.05 0.92
TM8X080B12MP11 CF/CM/CU24B 1.02 1.04 0.94
TM8X080B12MP11 CF/CM/CU30B 1.02 1.05 0.92
TM8X080C16MP11 CF/CM/CU24C 1.00 1.01 0.90
TM8X080C16MP11 CF/CM/CU30C 1.00 1.02 0.90
TM8X080C16MP11 CF/CM/CU30D 1.00 1.02 0.90
TM8X100C16MP11 CF/CM/CU24C 1.00 1.01 0.90
TM8X100C16MP11 CF/CM/CU30C 1.00 1.02 0.90
TM8X100C16MP11 CF/CM/CU30D 1.00 1.02 0.90
TM8X100C20MP11 CF/CM/CU30C 1.00 1.02 0.94
TM8X100C20MP11 CF/CM/CU30D 1.00 1.02 0.94
TM8X120C20MP11 CF/CM/CU30C 1.00 1.02 0.94
TM8X120C20MP11 CF/CM/CU30D 1.00 1.02 0.94
TM8Y060A12MP11 CF/CM/CU24A 1.00 1.00 0.92
TM8Y060A12MP11 CF/CM/CU30A 1.02 1.05 0.92
TM8Y080B12MP11 CF/CM/CU24B 1.02 1.04 0.94
TM8Y080B12MP11 CF/CM/CU30B 1.02 1.05 0.92
TM8Y080C16MP11 CF/CM/CU24C 1.00 1.01 0.90
TM8Y080C16MP11 CF/CM/CU30C 1.00 1.02 0.90
TM8Y080C16MP11 CF/CM/CU30D 1 1.02 0.9
TM8Y100C16MP11 CF/CM/CU24C 1.00 1.01 0.90
TM8Y100C16MP11 CF/CM/CU30C 1.00 1.02 0.90
TM8Y100C16MP11 CF/CM/CU30D 1.00 1.02 0.90
TM8Y100C20MP11 CF/CM/CU30C 1.00 1.02 0.94
TM8Y100C20MP11 CF/CM/CU30D 1.00 1.02 0.94
TM8Y120C20MP11 CF/CM/CU30C 1.00 1.02 0.94
TM8Y120C20MP11 CF/CM/CU30D 1.00 1.02 0.94
TM9E040A10MP11 CF/CM/CU24A 1.01 1.02 0.97
TM9E040A10MP11 CF/CM/CU30A 1.01 1.04 0.93
TM9E060B12MP11 CF/CM/CU24B 1.01 1.02 0.93
TM9E060B12MP11 CF/CM/CU30B 1.01 1.04 0.91
TM9E080B12MP11 CF/CM/CU24B 1.01 1.02 0.93
TM9E080B12MP11 CF/CM/CU30B 1.01 1.04 0.91
TM9E080C16MP11 CF/CM/CU24C 1.01 1.03 0.91
TM9E080C16MP11 CF/CM/CU30C 1.01 1.04 0.91
TM9E100C16MP11 CF/CM/CU24C 1.01 1.03 0.91
TM9E100C16MP11 CF/CM/CU30C 1.01 1.04 0.91
TM9E100C20MP11 CF/CM/CU24C 1.00 1.01 0.94
TM9E100C20MP11 CF/CM/CU30C 1.00 1.02 0.90
TM9E100C20MP11 CF/CM/CU30D 1.00 1.02 0.90
TM9E120D20MP11 CF/CM/CU30D 1.00 1.02 0.89
