5005749-CTG-A-0216
Johnson Controls Unitary Products 41
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO TH4B2421S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR COIL (°F)
ID CFM
600 800 1000
MBH COP KW MBH COP KW MBH COP KW
60
60 35.9 4.41 2.38 36.6 4.64 2.31 37.4 4.87 2.25
70 35.1 3.93 2.61 35.8 4.13 2.54 36.5 4.33 2.47
80 34.2 3.52 2.85 35.0 3.70 2.77 35.7 3.90 2.68
47
60 30.7 3.94 2.28 31.3 4.09 2.24 31.8 4.26 2.19
70 30.2 3.53 2.50 30.7 3.67 2.45 31.2 3.81 2.40
80 29.7 3.18 2.73 30.1 3.31 2.67 30.6 3.43 2.61
40
60 28.3 3.75 2.21 28.7 3.84 2.19 29.2 3.94 2.17
70 27.8 3.32 2.45 28.2 3.43 2.41 28.7 3.53 2.38
80 27.3 2.98 2.68 27.8 3.08 2.64 28.2 3.19 2.59
30
60 24.8 3.38 2.15 25.1 3.44 2.14 25.5 3.50 2.13
70 24.4 3.02 2.37 24.8 3.09 2.35 25.1 3.14 2.34
80 24.1 2.72 2.59 24.4 2.78 2.57 24.7 2.85 2.54
17
60 20.3 2.87 2.07 20.6 2.89 2.08 20.8 2.91 2.09
70 19.8 2.55 2.28 20.1 2.58 2.28 20.3 2.61 2.28
80 19.4 2.29 2.48 19.6 2.32 2.48 19.9 2.36 2.47
10
60 18.4 2.63 2.05 18.7 2.65 2.06 18.87 2.67 2.07
70 18.2 2.36 2.26 18.4 2.39 2.26 18.7 2.42 2.26
80 17.9 2.13 2.46 18.2 2.16 2.46 18.4 2.20 2.45
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Yellow shaded cells are AHRI High Heating conditions.
Orange shaded cells are AHRI Low Heating conditions.
COIL MULTIPLIERS - 2 TON
Air Handler Coil MBH COP KW
– CF/CM/CU24A 0.95 1.04 0.91
– CF/CM/CU24B 0.95 1.04 0.91
– CF/CM/CU24C 0.95 1.04 0.91
– CF/CM/CU30B 0.95 1.10 0.86
– CF/CM/CU30C 0.95 1.10 0.86
– CF/CM/CU30D 0.95 1.10 0.86
AE24BX21 – 0.95 1.11 0.86
AE30BX21 – 0.95 1.18 0.81
AP24BX21 – 0.95 1.04 0.91
AP30BX21 – 0.95 1.13 0.84
AVC24BX21 – 0.98 1.10 0.88
AVC30BX21 – 0.96 1.18 0.81
ME08BN21 CF/CM24B 0.95 1.11 0.86
ME08BN21 CF/CM30B 0.95 1.18 0.80
ME12BN21 CF/CM24B 0.95 1.10 0.86
ME12BN21 CF/CM30B 0.95 1.18 0.81
ME14DN21 CF/CM30D 0.95 1.15 0.82
ME16CN21 CF/CM24C 0.94 1.05 0.90
MVC08BN21 CF/CM24B 0.95 1.11 0.86
MVC08BN21 CF/CM30B 0.97 1.18 0.82
MVC12BN21 CF/CM24B 0.95 1.10 0.86
MVC12BN21 CF/CM30B 0.97 1.19 0.82
MVC14DN21 CF/CM30D 0.95 1.20 0.79
