Coleman TH4B6021S - Page 55

5005749-CTG-A-0216
Johnson Controls Unitary Products 55
COIL MULTIPLIERS - 3 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU48C 0.98 0.97 0.96
– CF/CM/CU48D 0.98 0.97 0.96
AE42CX21 – 0.99 1.00 0.88
AE48CX21 – 0.99 1.00 0.88
AE48DX21 – 1.00 1.00 0.88
AP37CX21 – 0.98 0.97 0.93
AVC42CX21 – 1.00 1.00 0.89
AVC48CX21 – 1.00 1.00 0.89
AVC48DX21 – 1.01 1.01 0.86
ME14DN21 CF/CM48D 1.00 1.00 0.87
ME16CN21 CF/CM48C 1.00 1.00 0.88
MVC14DN21 CF/CM48D 1.00 1.01 0.87
MVC16CN21 CF/CM48C 1.00 0.98 0.88
MVC20DN21 CF/CM48D 1.00 1.00 0.87
FURNACE MULTIPLIERS - 3 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP11 CF/CM/CU48C 1.00 1.00 0.90
TM8V100C16MP11 CF/CM/CU48C 1.00 1.00 0.90
TM8V100C20MP11 CF/CM/CU48D 0.98 0.97 0.89
TM8V120C20MP11 CF/CM/CU48D 0.98 0.97 0.89
TM8X080C16MP11 CF/CM/CU48C 0.99 0.99 0.90
TM8X080C16MP11 CF/CM/CU48D 0.99 0.99 0.90
TM8X100C16MP11 CF/CM/CU48C 0.99 0.99 0.90
TM8X100C16MP11 CF/CM/CU48D 0.99 0.99 0.90
TM8X100C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TM8X100C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TM8X120C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TM8X120C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TM8Y080C16MP11 CF/CM/CU48C 0.99 0.99 0.90
TM8Y080C16MP11 CF/CM/CU48D 0.99 0.99 0.90
TM8Y100C16MP11 CF/CM/CU48C 0.99 0.99 0.90
TM8Y100C16MP11 CF/CM/CU48D 0.99 0.99 0.90
TM8Y100C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TM8Y100C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TM8Y120C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TM8Y120C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TM9E080C16MP11 CF/CM/CU48C 0.99 0.98 0.91
TM9E080C16MP11 CF/CM/CU48D 0.99 0.98 0.91
TM9E100C16MP11 CF/CM/CU48C 0.99 0.98 0.91
TM9E100C16MP11 CF/CM/CU48D 0.99 0.98 0.91
TM9E100C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TM9E100C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TM9E120D20MP11 CF/CM/CU48D 0.99 0.99 0.90
TM9V080C16MP11 CF/CM/CU48D 1.00 1.00 0.88
TM9V100C16MP11 CF/CM/CU48D 1.00 1.00 0.88
TM9V100C20MP11 CF/CM/CU48C 0.99 0.97 0.91
TM9V100C20MP11 CF/CM/CU48D 0.99 1.00 0.89
TM9V120D20MP11 CF/CM/CU48D 0.99 1.00 0.89
TM9Y080C16MP11 CF/CM/CU48C 0.99 0.98 0.91
TM9Y080C16MP11 CF/CM/CU48D 0.99 0.98 0.91
TM9Y100C16MP11 CF/CM/CU48C 0.99 0.98 0.91
TM9Y100C16MP11 CF/CM/CU48D 0.99 0.98 0.91
TM9Y100C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TM9Y100C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TM9Y120D20MP11 CF/CM/CU48D 0.99 0.99 0.90
TMLV080C16MP11 CF/CM/CU48C 1.00 1.00 0.90
TMLV100C16MP11 CF/CM/CU48C 1.00 1.00 0.90
TMLV100C20MP11 CF/CM/CU48D 0.98 0.97 0.89
TMLV120C20MP11 CF/CM/CU48D 0.98 0.97 0.89
TMLX080C16MP11 CF/CM/CU48C 0.99 0.99 0.90
TMLX080C16MP11 CF/CM/CU48D 0.99 0.99 0.90
TMLX100C16MP11 CF/CM/CU48C 0.99 0.99 0.90
TMLX100C16MP11 CF/CM/CU48D 0.99 0.99 0.90
TMLX100C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TMLX100C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TMLX120C20MP11 CF/CM/CU48C 0.99 0.99 0.91
TMLX120C20MP11 CF/CM/CU48D 0.99 0.99 0.91
TP9C080C16MP11 CF/CM/CU48D 1.00 1.00 0.88
TP9C100C16MP11 CF/CM/CU48D 1.00 1.00 0.88
TP9C100C20MP11 CF/CM/CU48C 0.99 0.97 0.91
TP9C100C20MP11 CF/CM/CU48D 0.99 1.00 0.89
TP9C120D20MP11 CF/CM/CU48D 0.99 1.00 0.89
TPLC080C16MP11 CF/CM/CU48C 1.00 1.00 0.90
TPLC100C16MP11 CF/CM/CU48C 1.00 1.00 0.90
TPLC100C20MP11 CF/CM/CU48D 0.98 0.97 0.89
TPLC120C20MP11 CF/CM/CU48D 0.98 0.97 0.89
CP9C080C16MP11 CF/CM/CU48D 1.00 1.00 0.88
CP9C100C16MP11 CF/CM/CU48D 1.00 1.00 0.88
CP9C100C20MP11 CF/CM/CU48C 0.99 0.97 0.91
CP9C100C20MP11 CF/CM/CU48D 0.99 1.00 0.89
CP9C120D20MP11 CF/CM/CU48D 0.99 1.00 0.89
CPLC080C16MP11 CF/CM/CU48C 1.00 1.00 0.90
CPLC100C16MP11 CF/CM/CU48C 1.00 1.00 0.90
CPLC100C20MP11 CF/CM/CU48D 0.98 0.97 0.89
CPLC120C20MP11 CF/CM/CU48D 0.98 0.97 0.89
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. KW
