98
7
8
Route the cable through the handlebar with the help of a guiding
object (usually this is a mechanical shifter cable).
Fix the Shifters to the dropbar. Connect the EPS cable and the
Hydraulic hose lines following the specific instructions. Torque
setting is shown in the table at the end of this manual.
Integrated handlebar cable routing Integrated handlebar cable routing
9
The cockpit is ready. The EPS groupset cables and the hydraulic
hoses pass inside the stem. Place the spacers under the
handlebar if needed and cover the rear brake line with the noise-
cancelling rubber.
