Owner’s Guide 13
EN
4. Slide an eye shield onto the light guide. This will hold the
polyethylene barrier sleeve taut over the tip of the light
guide and hold it in place ready for the next use.
5. Verify the polyethylene lm barrier sleeve is still intact and
has not suffered damage such as tears or cuts. Store the
reassembled S.P.E.C. 3
®
LED Curing Light in a clean dry
location, preferably on the S.P.E.C. 3
®
LED charger base
so that the battery will be completely charged prior to the
next use.
VIII. Technical Details
8.1. Power Supply
A. Input: 100V–240V AC/50~60 Hz
B. Output: S.P.E.C. 3
®
: 6V DC, 2.5A
8.2. Dimensions
Component S.P.E.C. 3
®
Curing Light
Handpiece 174.5×24.8 (mm)
Power Adapter 47×87×32 (mm),
Charger Base 136×86×60 (mm),
AC Power Cord 1.3M
8.3. Environment
A. Operating Conditions
Temperature: -5°C~+40°C (23°F~104°F)
Relative Humidity: 10%~85%
Ambient Pressure: 80~106 kPa
(23.62 inHg~31.30 inHg)
B. Transportation and Storage Conditions
Temperature: -10°C~+45°C (14°F~113°F)
Relative Humidity: 10%~90%
Ambient Pressure: 60~106 kPa
(17.72 inHg~31.30 inHg)
