3
PARTS IDENTIFICATION
NOTE: DO NOT OBSTRUCT THE AIR INLET OR OUTLET.
Air-inlet Grille
Air Outlet
Wheel
Colzer Info
Control Panel
Drain Hose
Winder
Remove to
Access Pump
Wire Nail
Integrated Handle
(Foldable)
Handle Latch
Label Area
