51
Technical specifications
Receiver
Dimensions in mm (W × D × H)
210 × 145 × 45
Weight in grammes Receiver 660 g
Remote control 80 g (without batteries)
Input frequency range 950 MHz ~ 2'150 MHz
IF band width 55 MHz / 8 MHz (below 5MS/s)
LNB power supply 14V/18V GS, 0.30 A max.
Overload protection
LNB control 22 KHz ± 2 KHz, 0.6 V pp ± 0.2 V
DiSEqC control Version 1.0, Version 1.2, Tone-Burst
A/B
Symbol rate 1 ~ 35 MS/s
Bit stream ISO/IEC 115200 bit stream
specification
Input speed Max. 15 Mbit/s
Error correction (FEC) 1/2, 2/3, 3/4, 5/6, 7/8, auto
Aspect ratio 4:3 Letterbox, 4:3 PanScan, 16:9
Video resolution 720 x 576 (Pal), 720 x 480 (NTSC)
Audio mode Left, right, stereo, AC3 digital sound
Connection options
LNB IF input Type F, IEC 169-24
TV SCART (output only) Video CVBS, Audio L, R
VCR SCART (output and input) Video CVBS, Audio L, R
RCA (CINCH) Audio L,R
SPDIF, COAXIAL Digital audio output
Power supply
