COMBA COMFLEX Series - Equipment Constitution

USER MANUAL FOR COMFLEX-6Q00 5W
ENU STATUS: 1-0-1 Copyright - refer to title page Page 13
2.3 EQUIPMENT CONSTITUTION
MU consists of the following parts:
Table 1: MU Components
Module Description
MU01-RACK
Master Unit Chassis
includes
eight slots for RF Unit, two slots
for Fiber Optical
Unit, and one slot for Power Supply Unit.
MU01-PSU
iDAS Master Unit Power Supply Unit (PSU)
c
onverts
the input
voltage
into stable
DC to supply power for other modules of Master Unit.
MU01-FOU
Master Unit Fiber Optical Unit (FOU)
c
ompletes optical signal and RF signal
conversion. One FOU has four optical ports, which means each FOU can support
up to four RUs.
MU01-RFU
Master Unit RF Unit
c
ompletes separation and combination of uplink and downlink
signal with independent gain control, supports either simplex or duplex.
RU consists of the following parts:
Table 2: RU Components
Module Description
MRU01-6Q00
Medium Power Remote Unit (5W)
;
A
compact and slim design which support
s
3
bands, including 600MHz, WCS and TDD 2500MHz bands.
LRU01-PSU
Remote Unit Power Supply Unit (PSU)
converts
the input AC
voltage
into stable
DC, to supply power for Remote Unit. It can be installed on RU or on wall beside
RU.
