- 5 -
1. Press levers down on right and left harness hooks
to detach from buckle tongues.
2. Press buckle button down (with Combi logo) and
detach buckle tongues from buckle.
1. Place the crotch belt between the baby’s legs.
2. Insert buckle tongues into buckle.
3. Lift buckle with tongues inserted and attach right and left hook to holes in buckle
tongue
4. To adjust the harness or waist belt, loosen the slack on both sides of each
buckle.
or stand.
1. Unhook the shoulder straps from the center buckle as shown in
figure a.
2. Pull the back seat cushion forward and pull the shoulder straps
through the seat cushion as shown in figure b.
3. To raise the height, thread both shoulder straps through the
upper two loops. To lower the height, thread the shoulder straps
through the lower two loops as shown in figure c.
4. Thread the shoulder straps through the appropriate slot of the
seat cushion depending on which height the straps are set at as
shown in figure d.
figure a
figure b figure c figure d
changes in seating position.
1. To place the backrest in the upright postion, press
and hold down the button on the recline mecha-
nism and pull the strap tight while pushing the
recline mechanism toward the seat back.
2. To achieve a full recline, press and hold down the
button on the recline mechanism and pull down-
ward.
