DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-13
Option Board Type Description
AAM Automated Attendant Module
FL-VM Flash Voice Mail (with Automated Attendant)
PC-8 8-Port Hard Drive Voice Mail (with Automated Attendant)
Board Status can be any of the following:
Board Status Description
Fail/Failed This board is reporting some failure as a result of the last diagnostic
test. Also, this can indicate that CO lines are not connected to a CO
port or that Loop Current is no longer present on the CO lines
connected.
Open The board position is Open (not occupied, and likely never occupied).
Connect This board is reporting connected (installed and normal) status
Disconnect This board has been installed and is now removed.
Block/Unblocked This board/port is Blocked/Unblocked as part of a Maintenance service
function.
