Table 1
Value Unit Notes
RTD -
Py1 (Pt50), Py2 (Pt100), Py3 (Pt500), Py4 (Pt1000),
Py5 (Pt46-GOST), Py6 (Pt50-GOST), Py7 (Pt100-GOST),
Cw1 (Cu50, 1.426), Cw2 (Cu100, 1.426),
Cw3 (Cu50, 1.428), Cw4 (Cu100, 1.428)
T/C - yxJ (T/C "J"), yx" (T/C "K"), yxt (T/C "T")
current - $20 (4…20 mA), )20 (0…20 mA)
voltage - )10 (0…10 V)
-199 ... 999 ISU display offset value
0, 0.0 -
when indicating values with the input-signal measurement unit (ISU);
z (tens not shown), z (tens shown within the -19.9...99.9 range)
0 … 100 -
0 … 100 -
.C, .F -
This parameter makes sense ONLY in case of a temperature sensor!
-199 ... 999 ISU
-199 ... 999 ISU
These parameters make sense ONLY in case of a linear input signal!
Set Input Low < Input High!
0 ... 100 ISU
0...25% from span in case of a linear input signal
+7_, _g+
- +7_ - activates under set point, _g+
- activates over set point
0 ... 999 sec.
-199 ... 999 ISU For temperature input, the set point is limited for different sensor types!
oFF, con,
%[E, ALL
-
oFF(unlocked), con (Configuration level locked),
%[E(only set-point adjustment enabled), ALL (locked)
