Technical specifications
MAIN SPECIFICATIONS
Audio system Yes
Audio/video system Yes
Wall-mounted Ye s
Desk base-mounted Yes
Product colour White
Total buttons 2
LED signaling No
FUNCTIONS
Actuator control function Ye s
Switchboard call function Yes
Privacy function Yes
Floor door call function Yes
Electronic bell Yes
SETTINGS
Loudspeaker volume control Yes
Microphone volume control No
Ringtone volume control Ye s
GENERAL INFOI
Product height (mm) 190
Product width (mm) 103
Product depth (mm) 30
TECHNICAL SPECIFICATIONS
Power supply voltage 22÷35 Vdc
Power consumption stand-by (mA) 0,5÷0,710 Vdc
In called absorption (mA) 25÷30 mA
In communication absorption (mA) 23÷30 mA
Microphone Ø 9,6 x 6,9 mm
Loudspeaker Ø 0,50 mm ; Max Imput Power 0,5W
IP Rating 30
Operating temperature (°C) -5÷40
Product weight (g) 0,257 Kg
Clamps L,L,CFP,CFP
4
