Comelit 3348B - Programming Allowed Errors Number; Relay 1 Activation Delay for Remote Key Input; Actuator Function Programming

6
Example
To program key locking after 3 errors without sending an alarm, enter in sequence:
• 0 E start procedure
• 12345 E supercode
• 5 E error function
• 3 number of allowed errors
• 0 E do not send alarm
Programming the allowed errors number
This allows you to set the number of code entry errors allowed before the locking function is activated. If, for example, you
set a value of 3, on the third incorrect code entry the key is locked for a period of 1 minute. You can also send an alarm signal
(output AL+), after the allowed number of errors, if this is provided for during programming. To send the alarm, program “1”
during the procedure, otherwise program “0” (see below).
An incorrect code entry is the entry of a code not stored during programming, followed by “E”.
Programming the allowed errors number:
1. Enter “0” and “E” (start programming procedure code).
2. Check that the LED has lit up.
3. Enter the supercode (see "Entering the supercode"), then “E”.
4. Enter the number “5” (error lock function) followed by “E”.
5. Enter the allowed number of errors (1-9), but DO NOT enter “E”.
6. Enter: “1” “E” to send an alarm when the key is locked; “0” “E” if you do not wish to send an alarm.
7. The LED should now turn o.
Example
To set the activation time to 10 seconds, enter in sequence:
• 0 E start procedure
• 12345 E supercode
• 6 E Remote Key timing function
• 10 E relay activation time
Programming the relay 1 activation delay for a remote key input
This procedure sets the activation time for relay 1 on a remote input. Values from 1 to 99 can be set.
The default timing is 5 seconds.
Actuator function
One of the relays of 3348B can be used on the generic actuator command originating from the Simplebus Bus.
Special programming is required on the external unit as described in the TMs for Art. 4680, 4680C, 4681 and for 1621, 1622.
Programming the actuator function:
1. Enter “0” and “E” (start programming procedure code).
2. Check that the LED has lit up.
3. Enter the supercode (see "Entering the supercode"), then “E”.
4. Enter the number “7” ("actuator" function) followed by “E”.
5. Enter the number of the relay to be associated with the command (1-2) followed by “E”.
6. Enter a number from 1 to 99 to indicate the monostable mode seconds value, or enter "0" if you want bistable mode,
followed by “E”.
7. The LED should now turn o.
