Technical specifications
GENERAL INFO
Available codes 402 total available codes:
- one supercode;
- 400 relay codes. The available codes can be distributed in any way between
relay 1 and relay 2. Example: 245 dierent codes for relay 1, and 155 dierent
codes for relay 2;
- one anti-coercion code
Available outputs 2 on independent relays, plus 1 at 12 Vdc
Operation of the relay outputs keypad programmable, mono- or bistable
Monostable mode pulse programmable from 1” to 99” approx.
Supercode 1 to 8 repeatable digits
Relay codes 1 to 8 repeatable digits
Anti-coercion code 1 digit.
Remote key input Yes
Programming input Yes
Single-key operation mode input
(timetable programmer)
Yes
LED 3 LEDs, depending on model:
- 2 to indicate relay closure and 1 to indicate programming mode
Outputs (NO-NC), potential free Yes
Contact capacity 24V AC/DC MAX
Service output max 100 mA
Switch Switch (C) on the back of the module for selecting the LED lighting colour. Leave
the switch set to OFF for Simplebus systems
Operating temperature -10°C to +50°C
Product height (mm) 180
Product width (mm) 112
Product depth (mm) 43
ELECTRICAL SPECIFICATIONS
Power supply 12V AC/DC stand-alone. If connecting to a Simplebus system, use connector (B)
on the back of the module
Power Consumption 250 mA 12V AC with 2 relays active
System performance and layouts
For further information of system performance and to view installation layouts, click on the type of system that best meets your
needs :
• Building Kit audio/video system for the creation of audio-video systems for small apartment blocks.
• SBTOP audio/video system for the creation of audio-video systems for residential complexes.
• SB1 audio system for the creation of audio systems for residential complexes.
• SB2 audio system for the creation of audio systems for residential complexes.
